Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 5 Contacts, 2.54 mm Pitch, 1 Row 811-S1-005-10-015101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 811-S1-005-10-015101 |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 811 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Features 5 gold-plated brass contacts for superior conductivity.
- Designed with straight orientation and 1 row for easy through hole mounting.
- Housing made from fibreglass reinforced polyethylene terephthalate ensures durability.
- Operates at voltages up to 150 V and currents up to 3.5 A safely.
- Shrouded design prevents accidental contact and enhances safety.
- Suitable for operating temperatures ranging from -55°C to 125°C.
- Termination type is solder, compatible with standard PCB soldering processes.
- Compact size with 2.54 mm pitch and 2.54 mm row pitch for standard PCB layouts.
Product Description
Preci-Dip 811-S1-005-10-015101 is a spring loaded connector designed for reliable PCB connections in electronic assemblies. It features 5 gold-plated brass contacts arranged in one row with a standard 2.54 mm pitch, suitable for through hole mounting.
The connector housing is made of fibreglass reinforced polyethylene terephthalate, providing excellent mechanical strength and electrical insulation. Its shrouded design improves safety by preventing exposed contacts.
This model operates safely with voltages up to 150 V and can carry currents up to 3.5 A, making it ideal for various electronic and electrical applications requiring stable and low resistance connections.
The operating temperature range from -55°C to 125°C enables use in demanding environments including industrial and laboratory settings. The solder termination facilitates secure and robust PCB integration.
The spring loaded contact system ensures continuous reliable electrical contact even in conditions with mechanical vibration or movement, enhancing system durability and performance.
Features 5 gold-plated brass contacts for superior conductivity. Housing made from fibreglass reinforced polyethylene terephthalate. Straight orientation with one row and a 2.54 mm pitch. Shrouded connector enhances electrical safety.
Operates at voltages up to 150 V and currents up to 3.5 A. Suitable operating temperature from -55°C to 125°C. Solder termination type for PCB mounting. Manufactured in Switzerland with high precision standards. Spring loaded design provides low and stable contact resistance.
Compact and industry-standard pitch dimensions.
This connector is widely used in electronics manufacturing, industrial automation, measurement instruments, and communication equipment. Its robustness and reliable connection make it a preferred choice for demanding PCB interconnect solutions.
Explore more precision Connectors and components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates safely at voltages up to 150 V and can carry currents up to 3.5 A.
The connector features a standard pitch size of 2.54 mm.
The housing is made from fibreglass reinforced polyethylene terephthalate, providing excellent mechanical strength and electrical insulation.
It has a total of 5 gold-plated brass contacts.
The termination type for this connector is solder, which is compatible with standard PCB soldering processes.
It is suitable for operating temperatures ranging from -55°C to 125°C.
Yes, this model is specifically designed for through hole mounting.
The connector is designed with a straight orientation and features one row of contacts.
The shrouded design prevents accidental contact with the contacts, enhancing electrical safety.
This connector is manufactured in Switzerland, adhering to high precision standards.
It is widely used in electronics manufacturing, industrial automation, measurement instruments, and communication equipment.
The contact gender for this model is male.
