Preci-Dip 803 Series Right Angle PCB Socket, 10-Contact, 2 Row, 2.54 mm Pitch, 12A, 150V, Solder 803-87-010-20-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | PCB |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 10 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with black glass-filled polyester housing for durability.
- Contacts made from beryllium copper alloy with gold flash plating ensure reliable connectivity.
- Designed for right angle PCB mounting with solder termination type.
- Operates safely up to 150V voltage rating with a current capacity of 12 amperes.
- Rated for temperatures from -55°C minimum to 125°C maximum for versatile environments.
- Features female contact gender suitable for board-to-board connector systems.
- Complies with UL 94V-0 insulation flammability standard.
- Manufactured in Switzerland ensuring high quality and precision engineering.
Product Description
Preci-Dip 803-87-010-20-001101 is a high-quality right angle PCB socket designed for electronic components and power connectors applications. This socket connector offers 10 contacts configured in 2 rows with a 2.54 mm pitch, providing reliable board-to-board connectivity in demanding industrial and electronic manufacturing sectors.
The connector housing is fabricated from black glass-filled polyester, delivering excellent mechanical strength and electrical insulation properties. The contacts utilize beryllium copper alloy with a gold flash plating that enhances conductivity while providing corrosion resistance, leading to superior connection durability.
Intended for solder termination, this right angle socket supports applications operating up to 150 volts and can carry current up to 12 amperes, making it suitable for various electronic assemblies including industrial controls, instrumentation, and communication equipment.
Operating temperature ranges from -55°C to 125°C allow for dependable performance under harsh conditions common in industrial and manufacturing environments. The female contact gender design suits board-to-board connector systems with high-density interconnect requirements.
Durable black glass-filled polyester housing. Beryllium copper alloy contacts with gold flash plating for enhanced conductivity and corrosion resistance. Right angle orientation with solder termination for PCB mounting. Current rating of 12A and voltage rating of 150V for industrial usage.
Temperature tolerance from -55°C to 125°C for demanding environmental conditions. Female contact gender for secure board-to-board connection. UL 94V-0 standard compliance for flammability resistance. Swiss origin guaranteeing precision and quality.
This 803 series PCB Socket by Preci-Dip finds extensive application in electronic manufacturing, industrial machinery assembly, and power connectors in commercial and laboratory setups.
Browse EnvMart for more high-performance PCB connectors and electronic component accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this PCB socket is 150V, making it suitable for various electronic applications.
This model has a current capacity of 12A, allowing it to handle significant electrical loads in industrial applications.
The socket features 10 contacts arranged in 2 rows with a pitch of 2.54 mm, suitable for high-density interconnects.
The housing is made from black glass-filled polyester, while the contacts are constructed from beryllium copper alloy with gold flash plating for enhanced conductivity.
It operates safely within a temperature range of -55°C to 125°C, making it versatile for harsh environments.
This PCB socket utilizes solder termination, which is ideal for secure mounting on printed circuit boards.
It is designed for board-to-board connector systems, facilitating reliable connections between PCBs.
Yes, it complies with the UL 94V-0 insulation flammability standard, ensuring safety in applications.
The socket is designed for right angle orientation, which helps in optimizing space on the PCB.
This model is manufactured in Switzerland, ensuring high quality and precision engineering.
The socket features female contact gender, suitable for connecting with male connectors in board-to-board systems.
It is suitable for electronic manufacturing, industrial machinery assembly, and power connector applications.
