DiodesZetex Through Hole Hall Effect Sensor, 3 V to 28 V Supply, SOT-23W Package, 3-Pin AH3363Q-SA-7

DiodesZetex AH3363Q-SA-7 is a high-performance through hole Hall Effect Sensor IC designed for position and proximity sensing applications. This sensor uses a chopper stabilised technology to provide stable and accurate linear output with minimal offset and drift, ideal for industrial, automotive, and electronic applications.

The sensor supports a wide supply voltage range from 3 V to 28 V, ensuring compatibility with various power configurations. It features unipolar magnetic sensing, reacting to one magnetic polarity, making it suitable for magnetic switch and proximity detection systems.

Its compact SOT-23W package with three pins allows easy mounting on printed circuit boards using through hole technology. The 3-pin configuration simplifies integration into electronic designs. Furthermore, the AH3363Q-SA-7 is AEC-Q100 qualified, making it compliant with automotive industry standards and demanding environmental conditions.

The device operates effectively across a broad temperature range from -40°C to 150°C, enabling use in harsh industrial and automotive environments. With a low supply current of 3 mA and a rapid response time of 3.75 microseconds, this sensor is efficient and responsive for real-time applications.

The sensor supports a maximum frequency response of 800 kHz, meeting requirements for high-speed signal processing. Its dimensions (length 3 mm, width 1.4 mm, height 1 mm) make it suitable for compact electronic assemblies where space-saving is critical.

Uses chopper stabilised technology to reduce offset and noise. Unipolar magnetic sensor suitable for non-contact switching. Wide operating voltage from 3 V to 28 V for versatile use. Through hole mount type in a compact SOT-23W package.

Automotive AEC-Q100 standard certified for reliability. RoHS compliant and antimony-free material construction. Supports operation from -40°C up to 150°C ambient temperature. Low power consumption with 3 mA supply current.

Fast response time of 3.75 μs for quick magnetic detection. Physical size optimized for space-constrained designs.

This Hall Effect Sensor is ideal for industrial automation, automotive position sensing, electronic instrumentation, and laboratory equipment. It provides precise and reliable magnetic sensing for non-contact switching and proximity detection applications in demanding environments.
