Mean Well Ultra Slim Switched Mode DIN Rail Power Supply 48 V DC, 92.2 W, 1.92 A Output HDR-100-48
Specifications
| Country of Origin | China |
|---|---|
| Brand | Mean Well |
| Power | 92.2W |
| Efficiency | 90% |
| Height | 90mm |
| Model | HDR-100-48 |
| Depth | 54.5mm |
| Width | 70mm |
| Series | Ultra Slim |
| Output Current | 1.92A |
| Maximum Operating Temperature | 70°C |
| Sub Type | Switched Mode |
| Minimum Operating Temperature | -30°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 370, 264V dc |
| Electrical Phase | 1 |
| Standards/Approvals | TUV EN 609501, UL, RoHS |
| Maximum Output Voltage | 48V dc |
| Minimum Input Voltage | 85V ac |
Key Features
- The unit features a compact and space-saving ultra-slim design suitable for TS-35/7.5 or TS-35/15 DIN rails.
- It supports full range AC/DC input voltage with a minimum of 85 V AC and maximum input voltage of 264 V AC or 370 V DC.
- The power supply provides adjustable DC output voltage and has a load power consumption efficiency of 90%.
- Operating temperature ranges from -30°C to 70°C ensuring reliable performance in industrial environments.
- It is constructed with plastic housing for electrical hazard protection and complies with TUV EN 60950-1, UL, and RoHS standards.
- The device is designed for single output phase with isolation class II and no hazardous area certification required.
Product Description
Mean Well HDR-100-48 Ultra Slim Switched Mode DIN Rail Power Supply delivers a maximum output power of 92.2 W with 48 V DC output voltage and 1.92 A output current. It supports both AC and DC input voltages, ranging from 85 V AC minimum to 264 V AC or 370 V DC maximum input. This power supply unit (PSU) features an ultra-slim, stepped shape plastic housing that enables compact space-saving installation on TS-35/7.5 or TS-35/15 industrial DIN rails.
Designed for use in industrial automation, electronic control panels, HVAC systems, manufacturing lines, and other commercial electrical equipment, it ensures steady power delivery with an efficiency of 90%. The device operates reliably within a wide temperature range spanning from -30°C to 70°C, making it suitable for harsh industrial environments.
The PSU is constructed with Class II insulation and plastic housing for electrical hazard prevention. It carries recognized certifications including TUV EN 60950-1, UL listed, and RoHS compliance, assuring safety and environmental standards. The unit provides a single DC output and has no hazardous area certification requirements.
Physical dimensions are 90 mm in height, 70 mm in width, and 54.5 mm in depth, offering easy integration into control cabinets and reducing space occupation. The compact ultra slim form factor saves valuable cabinet space during installation.
Full range AC/DC input capability supports wide voltage variations. High operational efficiency enhances energy savings and reduces heat generation. Adjustable DC output voltage enables precise power delivery suited to different load needs.
Wide operating temperature range suits challenging industrial conditions. Robust plastic housing ensures electrical safety and insulation. Certified compliances reinforce quality and safety standards. This power supply is ideal for industrial, manufacturing, automation, and HVAC applications where reliable, efficient, and compact DIN rail mounted power solutions are required.
Explore additional power supply options and related accessories within the Electronics & Electricals category at EnvMart for comprehensive industrial powering needs.
Explore more products in our DIN Rail Power Supplies category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 92.2 W.
It supports an input voltage range from 85 V AC to 264 V AC or 370 V DC.
It provides a DC output voltage of 48 V and an output current of 1.92 A.
This power supply has dimensions of 90 mm in height, 70 mm in width, and 54.5 mm in depth.
The HDR-100-48 has a load power consumption efficiency of 90%.
It operates reliably within a temperature range of -30°C to 70°C.
It complies with TUV EN 60950-1, UL, and RoHS standards.
It is designed for mounting on TS-35/7.5 or TS-35/15 DIN rails.
Yes, the HDR-100-48 features an adjustable DC output voltage.
It features Class II insulation for electrical hazard protection.
This power supply is suitable for industrial automation, electronic control panels, HVAC systems, and manufacturing lines.
It operates on a single output phase.
