Vishay DC Input Optocoupler Through Hole 6-Pin PDIP CNY75B
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | CNY75B |
| Mount Type | Through Hole |
| Series | CNY |
| Maximum Operating Temperature | 110°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -55°C |
| Maximum input current | 60mA |
| Number Of Channels | 1 |
| Maximum Forward Voltage | 1.6V |
| Number of Pins | 6 |
| Input Current Type | DC |
| Typical Rise Time | 3μs |
| Maximum Current Transfer Ratio | 200% |
| Typical Fall Time | 3.7μs |
| Minimum Current Transfer Ratio | 100% |
Key Features
- Mount Type is Through Hole for easy PCB integration.
- Provides 1 channel for signal isolation.
- Maximum input current rating is 60mA for reliable operation.
- Features a typical rise time of 3 microseconds ensuring fast signal response.
- Maximum current transfer ratio reaches up to 200% enhancing signal amplification.
- Complies with various certifications including BS EN 41003 and UL1577.
- Typical fall time is 3.7 microseconds for efficient switching.
- Supports a minimum current transfer ratio of 100% for consistent performance.
Product Description
Vishay CNY75B DC Input Optocoupler is a high-quality semiconductor device designed to provide electrical isolation between input and output circuits in electronic systems. Housed in a 6-pin PDIP through-hole package, this optocoupler is ideal for industrial, electronic instrumentation, and power management applications requiring reliable and fast signal transmission.
This device supports a maximum forward voltage of 1.6V and an input current up to 60mA, with excellent isolation voltage rated at 5kVrms. It operates effectively over a wide temperature range from -55°C to 110°C, making it suitable for harsh environmental conditions.
The typical rise time of 3 microseconds and fall time of 3.7 microseconds ensure rapid switching capabilities, while the current transfer ratio ranges from a minimum of 100% to a maximum of 200%, providing excellent signal amplification performance.
The Vishay CNY75B meets numerous industry standards and approvals including BS EN 41003, UL1577, FIMKO (SETI), EN 60950, DIN EN 60747-5-5 (VDE 0884), BS EN 60950 (BS 7002), and BS EN 60095 (BS 415), assuring compliance and reliability for critical applications.
This optocoupler is widely used in electronic control systems, power supplies, automation equipment, and safety interlock circuits. Its design enables effective noise isolation and protection for sensitive components in industrial, laboratory, and HVAC equipment.
Mount Type is Through Hole for easy PCB integration. Provides 1 channel for signal isolation. Maximum input current rating is 60mA for reliable operation. Features a typical rise time of 3 microseconds ensuring fast signal response.
Maximum current transfer ratio reaches up to 200% enhancing signal amplification. Complies with various certifications including BS EN 41003 and UL1577. Typical fall time is 3.7 microseconds for efficient switching. Supports a minimum current transfer ratio of 100% for consistent performance.
Manufactured under the Vishay CNY series for semiconductor optocouplers. Explore more electronic components and Optocouplers from EnvMart to meet your industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input current rating for the CNY75B is 60mA, ensuring reliable operation in various applications.
The typical rise time of the CNY75B is 3 microseconds, which allows for fast signal response.
This optocoupler has a maximum current transfer ratio of up to 200%, enhancing signal amplification.
The CNY75B operates effectively over a temperature range from -55°C to 110°C, making it suitable for harsh environments.
The CNY75B is housed in a 6-pin PDIP through-hole package, facilitating easy PCB integration.
The CNY75B provides 1 channel for signal isolation.
The typical fall time of the CNY75B is 3.7 microseconds, ensuring efficient switching performance.
The maximum forward voltage for this model is 1.6V.
The CNY75B complies with several certifications including BS EN 41003 and UL1577, ensuring reliability for critical applications.
The input current type for the CNY75B is DC, making it suitable for various electronic applications.
The CNY75B is part of the Vishay CNY series of semiconductor optocouplers.
The CNY75B is manufactured in India.
