TE Connectivity PIDG Insulated Ring Terminal M2.5 Stud Size 22 AWG to 16 AWG Wire Size Red 130522
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Red |
| Model | 130522 |
| Insulation | Insulated |
| Overall Length | 19.6mm |
| Contact Material | Copper |
| Series | PIDG |
| Maximum Operating Temperature | 105°C |
| Insulation Material | Nylon |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 0.3mm² |
| Maximum Wire Size mm² | 1.3mm² |
| Minimum Wire Size AWG | 22AWG |
| Maximum Wire Size AWG | 16AWG |
| Stud Size | M2.5 |
Key Features
- Constructed with high conductivity copper body for excellent electrical performance.
- Features a copper sleeve for enhanced wire insulation support after crimping.
- Serrations inside the wire barrel provide superior contact and tensile strength.
- Color-coded nylon insulation sleeve for easy wire size identification.
- Funnelled wire entry design enables fast wire insertion and reliable crimps.
- Suitable for various industrial, automotive, aerospace, and appliance applications.
- Designed to meet or exceed MIL-T-7928, Type II, Class 1 and 2 standards.
- Maximum operating temperature of 105°C offers durability under high-heat conditions.
Product Description
TE Connectivity 130522 PIDG Insulated Ring Terminal M2.5 Stud Size, suitable for wire sizes from 22 AWG to 16 AWG with a red insulation sleeve, offers reliable, uniform crimps and high electrical conductivity for professional wiring applications.
This ring terminal features a precision-formed copper contact body coupled with a copper sleeve and nylon insulation for enhanced mechanical and thermal stability. The color-coded nylon insulation aids in quick wire size identification while providing durability and electrical safety. Inside the barrel, serrations ensure excellent electrical contact and tensile strength, preventing wire slippage.
The funnelled wire entry allows quick and easy wire insertion, making it ideal for high-volume production environments. These terminals are designed to provide uniform insulation thickness under crimping pressure, resulting in consistent, reliable crimps.
These terminals comply with demanding industrial and military standards including MIL-T-7928. They are widely used in automotive, aerospace, appliance manufacturing, instrumentation, control panels, power supply connections, and transportation equipment wiring.
The red nylon insulation supports a wire range from 22 AWG (0.3 mm²) to 16 AWG (1.3 mm²), with a maximum operating temperature of 105°C. This ensures the terminal's performance in harsh environments and elevated temperatures.
High conductivity copper body for superior electrical flow. Copper sleeve enhances wire insulation support post-crimp. Serrated barrel provides optimal contact and mechanical grip on wire. Color-coded nylon sleeves simplify wire gauge identification.
Funnelled wire entry design improves assembly efficiency. Suitable for instrumentation, automotive, aerospace, and more. Designed to meet or exceed MIL-T-7928 standards. Maximum operating temperature of 105°C for thermal durability.
Ensure your electrical connections are secure and reliable with the TE Connectivity PIDG Insulated Ring Terminal 130522. Explore more from TE Connectivity and related categories at EnvMart for comprehensive solutions in wire terminals and splices.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This insulated ring terminal accommodates wire sizes from 22 AWG (0.3 mm²) to 16 AWG (1.3 mm²).
The maximum operating temperature of this terminal is 105°C, making it suitable for high-heat applications.
It features a copper contact body and a copper sleeve, with nylon insulation for enhanced mechanical and thermal stability.
The funnelled wire entry design allows for quick and easy wire insertion, improving assembly efficiency in production environments.
It is designed to meet or exceed MIL-T-7928, Type II, Class 1 and 2 standards, ensuring reliability in demanding applications.
The overall length of this insulated ring terminal is 19.6 mm.
The insulation on this terminal is red, which also aids in quick wire size identification.
The serrated barrel provides superior contact and tensile strength, preventing wire slippage and ensuring reliable electrical connections.
This terminal is suitable for various applications including automotive, aerospace, appliance manufacturing, and control panels.
The stud size of this terminal is M2.5.
The insulation material used is nylon, which provides durability and electrical safety.
The copper sleeve enhances wire insulation support after crimping, contributing to the terminal's overall performance and reliability.
