TE Connectivity PCB Power Relay, 5V dc Coil, 16A Switching Current, SPDT RT314F05

TE Connectivity RT314F05 is a PCB Power Relay featuring a 5V DC coil and 16A switching current in a SPDT (Single Pole Double Throw) configuration. This relay is part of the SCHRACK series designed for PCB mount applications with solder terminals, providing easy and reliable integration into electronic circuits.

Operating between -40°C and 85°C, the RT314F05 relay caters to demanding industrial, automation, and electrical applications requiring dependable switching performance. Its coil resistance of 42 ohms optimizes coil power consumption while allowing for stable actuation.

The relay supports switching voltages up to 400V AC and can handle switching powers up to 4 kVA, suitable for a variety of load types in automation, manufacturing equipment, and control systems. Its silver alloy contacts ensure robust conductivity and long service life.

With compact size - length 29mm, width 12.7mm, height 15.7mm - it fits well in space-constrained PCB layouts. The device conforms to RoHS standards, ensuring it meets environmental and safety compliance requirements.

The RT314F05 from TE Connectivity belongs to the RT1 & RT2 series of bistable/latching relays designed for applications requiring a memory function, such as battery-powered devices and systems needing state retention during power loss. It features reinforced insulation and a high degree of shock resistance, withstanding destructive shocks up to 100g, making it suitable for industrial and commercial use.

Designed for PCB mounting with solder terminals for secure connection. Operates within a temperature range of -40°C to 85°C for versatile applications. Features a coil resistance of 42 ohms ensuring efficient coil operation.

Switching capability up to 400V AC and 4kVA switching power supports demanding electrical loads. Constructed with silver alloy contacts providing excellent conductivity and durability. Compact dimensions with a length of 29mm, width 12.7mm, and height 15.7mm suitable for tight spaces.

RoHS compliant for environmental safety and quality assurance. Typically used in battery powered equipment and memory function applications due to bistable/latching design. Reinforced insulation and shock resistance enhance reliability in industrial use.

This relay is ideal for industrial automation, electronic control panels, HVAC systems, and manufacturing equipment that require reliable switching and energy efficiency. Its design supports applications where durable and precise control of power circuits is critical.
