MEAN WELL SD-25C-5 DC/DC Converter 5V DC Output, 36-48V DC Input, 5A Output Current, 25W Power, Chassis Mount SD-25C-5

MEAN WELL SD-25C-5 is a high-reliability DC/DC Converter designed for industrial and electronic applications requiring a regulated 5V output voltage powered by a DC input voltage range from 36V to 48V. This chassis mount converter features a compact size, making it ideal for space-restricted installations.

The device provides a maximum output current of 5A and an output power capacity of 25W, allowing it to support moderate power loads while maintaining efficiency. The output voltage is adjustable up to 5.5V to accommodate precise voltage requirements. It ensures user safety and system integrity through 1.5kV input/output isolation.

Its rugged design complies with internationally recognized EMC standards ensuring low electromagnetic interference and compatibility with other industrial equipment. The included protections against short circuit, overload, and overvoltage increase system robustness and durability in harsh environments.

The converter operates reliably within a temperature range of -10°C to 60°C, suitable for various industrial, laboratory, manufacturing, and commercial applications.

The built-in LED power indicator facilitates easy status monitoring. Screw terminal mount type ensures the product can be securely installed and maintained. Its mean time between failures (MTBF) of 377,500 hours underscores the long-term dependability of the product.

Provides a stable 5V DC output voltage with adjustable range up to 5.5V. Input voltage range supports wide operation between 36V and 48V DC. Maximum output current of 5A and output power capacity of 25W. Designed with 1.5kV AC isolation for safe operation and noise reduction.

Equipped with screw terminal connectors for easy installation and stable mounting. Compact dimensions of 99mm length, 97mm width, and 36mm depth for space-efficient integration. Operating temperature range from -10°C to 60°C ensures reliable performance in diverse environments.

Complies with EN 61000-4-2, ENV 50204, and EN 55022 Class B EMC standards. Features LED power-on indicator and protection against short circuit, overload, and overvoltage conditions. Average reliability with MTBF of 377,500 hours guarantees product longevity.

This MEAN WELL SD-25C-5 DC/DC Converter is well suited for use in industrial equipment, power supplies, communication devices, instrumentation, and automation systems requiring stable and isolated DC power conversion.
