ASSMANN WSW A-DS 15 Way Right Angle 2.77 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock A-DS 15 A/KG-T1

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW A-DS 15 Way Right Angle 2.77 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock A-DS 15 A/KG-T1

Name: ASSMANN WSW A-DS 15 Way Right Angle 2.77 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock A-DS 15 A/KG-T1
Brand: ASSMANN WSW
SKU: 208379



Category D-Sub Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V
Brand	ASSMANN WSW
Orientation	Right Angle
Current	3A
Model	A-DS 15 A/KG-T1
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	A-DS
Mounting Hardware	4 to 40 UNC Screw Lock
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Pitch	2.77mm
Contact Plating	Nickel, Gold
Number of Contacts	15
Contact Gender	Male
Connector Type D	D-Sub

Key Features

Rated for 3A current and 250V voltage operation.
Equipped with 4 to 40 UNC screw lock mounting hardware for secure fixation.
Housing material is durable polybutylene terephthalate ensuring robust mechanical stability.
Designed for solder termination with male contact gender.
Operating temperature range from -40°C to 105°C suitable for various industrial environments.
Standard A-DS series with no specific certifications.
15 contacts ensure multiple signal or power connections in a compact form.
Right angle orientation reduces PCB real estate and improves cable routing.

Product Description

ASSMANN WSW A-DS 15 A/KG-T1 is a 15 Way Right Angle D-Sub Connector with a 2.77 mm pitch, designed for through hole PCB mounting applications. Manufactured from polybutylene terephthalate housing with brass contacts plated in nickel and gold, this connector ensures reliable electrical performance and mechanical durability.

Rated at 3A current and 250V voltage, it is ideal for electronics assemblies requiring secure and high-quality connector solutions. The right angle orientation facilitates compact PCB layouts and ease of connection in tight spaces. The 4 to 40 UNC screw lock mechanism guarantees secure mounting and vibration resistance.

This connector features a solder termination type with male contact gender, making it suitable for various soldering processes commonly used in industrial manufacturing, automation, and electronic device assembly. Its temperature range of -40°C to 105°C allows use in demanding environments, including industrial automation, instrumentation, and control systems.

Although it does not carry additional standards or approvals, the robust build and material quality make it well-suited for demanding industrial and commercial applications. Originating from China, this connector belongs to the A-DS series known for Euro-Standard D-Sub Connectors with right angled designs.

15 contacts ensure multiple signal or power connections in a compact form. Right angle orientation reduces PCB real estate and improves cable routing. Through hole mounting provides strong mechanical connection in PCB assemblies.

Polybutylene terephthalate housing offers impact resistance and electrical insulation. Nickel and gold plated contacts assure corrosion resistance and reliable conductivity. Solder termination ensures stable electrical contact and ease of assembly.

Wide operating temperature range supports diverse industrial environments. 4 to 40 UNC screw lock mounting hardware improves connection security.

This ASSMANN WSW connector suits electronic manufacturing, industrial automation, equipment assembly, and maintenance tasks, providing dependable connectivity. Explore more connectors and electronic components on EnvMart for comprehensive solutions.
