Microchip Surface Mount Positive Voltage Regulator 6V 3-Pin MCP1826S-3302E/EB

Free Delivery in India | Lowest Global Shipping Charges

Microchip Surface Mount Positive Voltage Regulator 6V 3-Pin MCP1826S-3302E/EB

Name: Microchip Surface Mount Positive Voltage Regulator 6V 3-Pin MCP1826S-3302E/EB
Brand: Microchip
SKU: 205836



Category Voltage Regulator Brand Microchip Condition New

Specifications

Country of Origin	India
Voltage	Regulators Microchip, Voltage Regulator 6V 3-Pin RS Stock No
Brand	Microchip
Height	4.83mm
Length	10.67mm
Model	MCP1826S-3302E/EB
Width	9.65mm
Mount Type	Surface
Series	MCP1826S
Maximum Operating Temperature	125°C
Polarity	Positive
Maximum Input Voltage	6V
Quiescent Current	120μA
Standards/Approvals	ESD Protection (HBM/MM)
Minimum Input Voltage	2.3V
Pin Count	3
Automotive Standard	AEC-Q101

Key Features

Surface mount design optimized for compact PCB layouts.
Positive polarity voltage regulation with a 6V maximum input voltage.
Low quiescent current of 120μA reduces power consumption.
Three pin count allows easy integration into circuits.
Supports automotive standard AEC-Q101 for high reliability.
Maximum operating temperature rating of 125°C allows use in harsh environments.
ESD protection compliant with Human Body Model and Machine Model standards.

Product Description

Microchip MCP1826S-3302E/EB is a surface mount positive voltage regulator designed for precise voltage control in electronic applications requiring regulated 6V output. This three-pin low dropout (LDO) linear regulator is ideal for power management in both consumer electronics and automotive systems.

The compact package dimensions of 10.67mm length, 9.65mm width, and 4.83mm height ensure it fits well on densely packed circuit boards. Featuring a low quiescent current of 120μA, it minimizes power losses and enhances overall energy efficiency of the circuit.

This regulator supports a wide input voltage range from 2.3V up to 6V, making it versatile for varying power supply sources. It complies with automotive standard AEC-Q101 which guarantees robustness and reliability required in vehicular electronics. The device also incorporates ESD protection compliant with both Human Body Model (HBM) and Machine Model (MM) standards, ensuring durability against electrostatic discharges.

The MCP1826 series is designed for industrial, automotive, and consumer electronic applications, including power supply regulation for microcontrollers, sensors, and communication devices. Its rugged temperature tolerance up to 125°C allows stable operation in demanding environments such as automotive engine compartments or industrial controls.

Surface mount design optimized for compact PCB layouts. Positive polarity voltage regulation with a 6V maximum input voltage. Low quiescent current of 120μA reduces power consumption. Compact dimensions: 10.67mm length, 9.65mm width, and 4.83mm height.

Three pin count allows easy integration into circuits. Supports automotive standard AEC-Q101 for high reliability. Maximum operating temperature rating of 125°C allows use in harsh environments. ESD protection compliant with Human Body Model and Machine Model standards.

Choose the Microchip MCP1826S-3302E/EB for dependable voltage regulation in power management IC designs. Explore more power management ICs and Voltage Regulators at EnvMart.
