TE Connectivity PCB Power Relay SPDT 48V DC Coil 6A Switching Current SNR Series V23092A1048A301

TE Connectivity V23092A1048A301 PCB Power Relay is part of the SNR Series known for their slim, compact designs suited for high density printed circuit board (PCB) mounting. This power relay offers a 48V DC coil voltage and supports a switching current of 6 amperes, making it suitable for electrical and industrial automation applications requiring reliable control of medium power circuits.

The relay utilizes a single-pole double-throw (SPDT) contact arrangement fitted with silver alloy contacts to ensure durable conductivity and low contact resistance. Its minimal footprint with dimensions of 28mm length, 15mm height, and 5mm thickness allows for efficient PCB layout in space-constrained designs.

Engineered to operate in a wide temperature range from -40°C up to 85°C, this relay is robust enough for harsh industrial environments. The coil resistance is 10.6 kΩ, with a coil power of 217mW and high sensitivity at 170mW, helping reduce power consumption during switching operations.

Designed for solder terminal mounting, the relay ensures secure and reliable electrical connections on the PCB. It is capable of switching AC voltages up to 400V with a maximum switching power of 1.5 kVA, suitable for controlling a variety of AC loads.

With an isolation voltage rating of 4000 VAC between coil and contact, the relay ensures high safety standards, minimizing risks of electrical interference or damage. The product complies with RoHS standards, supporting environmental and safety requirements.

This relay is ideal for electrical, industrial automation, signal conditioning, and manufacturing applications where compact, efficient, and reliable switching components are needed.

Features a single-pole double-throw (SPDT) contact configuration. Coil voltage rating of 48V DC for efficient switching. Supports a maximum switching current of 6 amperes. Compact dimensions of 28mm length, 15mm height, and 5mm width.

Operating temperature range from -40°C to +85°C. High coil sensitivity of 170 mW with coil power of 217 mW. Constructed with silver alloy contact material ensuring durable electrical performance. Designed for PCB mount using solder type terminals.

Capable of switching AC voltage up to 400V AC with 1.5 kVA switching power. Isolation voltage of 4000 VAC between coil and contact for safety. Explore more from the Power Relays category at EnvMart for additional industrial electrical components and solutions.
