Panasonic PCB Power Relay 5V DC Coil 10A Switching Current SPDT ALQ1F05

Panasonic ALQ1F05 PCB Power Relay is a high-performance and compact power relay designed for PCB mounting. It operates with a coil voltage of 5V DC and can switch currents up to 10A with a Single Pole Double Throw (SPDT) contact configuration. The relay is suitable for various industrial, automation, and electrical applications requiring reliable switching under demanding conditions.

Measuring 20mm in length, 15.6mm in height, and 10mm in width, this relay offers a compact solution without compromising performance. It supports switching power up to 500VA and switching DC voltages up to 30V, making it versatile for different power circuits.

The coil resistance of 62.5 ohms and coil power consumption of 400mW contribute to efficient energy use. Its operating temperature range from -40°C to +85°C ensures consistent functionality in both cold and hot environments. The relay's silver alloy contacts provide low contact resistance of 100mΩ, enhancing switching reliability and reducing signal loss.

With high surge voltage tolerance of 8000 V and breakdown voltage of 4000 V, the Panasonic ALQ1F05 relay is designed to endure voltage spikes and harsh electrical conditions, extending equipment lifespan. The PCB mounting type with PCB pin terminals facilitates easy and secure integration onto printed circuit boards.

This model complies with internationally recognized certifications including VDE, UL, cULus, cUL, CSA, and CQC, endorsing its safety and quality standards.

Common applications include use in appliances, industrial machinery, robotics, power supply control, HVAC systems, and lighting control, where robust and dependable relay performance is critical.

Choose Panasonic ALQ1F05 PCB Power Relay for compact, reliable, and high-performance relay switching solutions in industrial and commercial electronic circuits. Explore more Power Relays and industrial electrical components at EnvMart.

Compact size with 20mm length, 15.6mm height, and 10mm width dimensions. High switching power capability of up to 500VA and switching DC voltage up to 30V. Coil resistance of 62.5 ohms and coil power consumption of 400mW for efficient operation.

Operational temperature range from -40°C to 85°C ensuring performance in extreme conditions. Silver alloy contact material and low contact resistance of 100mΩ enable reliable switching. High surge voltage resistance of 8000 V and breakdown voltage of 4000 V for durability.

PCB mounting with PCB pin terminal type for easy integration in circuit boards. Certified with standards including VDE, UL, cULus, cUL, CSA, and CQC.
