Panasonic PCB Power Relay 5V DC Coil 16A Switching Current SPST ADW1205HLW
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.8mm |
| Length | 24mm |
| Model | ADW1205HLW |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ADW1 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 16A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | VDE, UL, TV-8, PTI 325V, cULus, cUL, CSA |
| Coil Resistance | 62.5Ω |
| Coil Voltage | 5V dc |
| Switching AC Voltage | 277V ac |
| Coil Power | 400mW |
Key Features
- The relay features a compact design suitable for PCB mounting.
- Operates reliably from -40°C to 70°C ambient temperature.
- Utilizes a silver alloy contact material for low resistance and durability.
- Supports a maximum switching AC voltage of 277V.
- The coil power consumption is 400mW with a resistance of 62.5Ω.
- Complies with standards including VDE, UL, cULus, and CSA for safety and quality.
- Ideal for applications in appliances, lighting controls, smart meters, and industrial power supplies.
Product Description
Panasonic ADW1205HLW is a reliable PCB power relay featuring a 5V DC coil and a single pole single throw (SPST) contact configuration capable of switching 16A current at up to 277V AC. The relay's compact size allows efficient PCB mounting while maintaining high operational robustness in industrial and commercial environments.
The device operates within a temperature range from -40°C to 70°C, ensuring dependable performance under diverse thermal conditions. It uses silver alloy contacts that guarantee low contact resistance of 100mΩ and enhanced durability, making it suitable for long-term applications.
With coil resistance of 62.5Ω and coil power of 400mW, this relay is energy efficient while maintaining rapid response. Its dimensions of 24mm in length, 15.8mm height, and 10mm width facilitate easy integration into various electronic circuits.
Certified by multiple standards such as VDE, UL, TV-8, PTI 325V, cULus, cUL, and CSA, the ADW1205HLW meets stringent safety and quality requirements. These features make it well-suited for use in appliances, white goods, industrial power supplies, lighting controls, and smart meters.
The relay is compact and robust, ideal for demanding industrial applications. Robust contact system ensures reliable switching at high currents. Wide operating temperature range supports versatile environments. Silver alloy contact material lowers resistance and enhances durability.
Meets multiple international safety and performance standards. Energy-efficient coil with 400mW power consumption and 62.5Ω resistance. Dimensions optimized for PCB mounting in compact designs. Explore EnvMart's extensive range of Panasonic Power Relays to meet your industrial and electronic component needs with confidence.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay can switch a maximum current of 16A.
This model operates with a coil voltage of 5V DC.
It operates reliably within a temperature range of -40°C to 70°C.
The relay features a single pole single throw (SPST) contact configuration.
The dimensions are 24mm in length, 15.8mm in height, and 10mm in width.
It utilizes silver alloy as the contact material, which provides low resistance and durability.
The relay supports a maximum switching AC voltage of 277V.
The coil power consumption is 400mW.
It complies with multiple standards including VDE, UL, cULus, and CSA for safety and quality.
The contact resistance is 100mΩ, ensuring efficient operation.
This model is designed for PCB mounting, making it compact and efficient for electronic circuits.
It is ideal for applications in appliances, lighting controls, smart meters, and industrial power supplies.
