Phoenix Contact 50-Contact Female Interface Module D-Sub Connector DIN Rail Mount 2.5A 2962764

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact 50-Contact Female Interface Module D-Sub Connector DIN Rail Mount 2.5A 2962764

Name: Phoenix Contact 50-Contact Female Interface Module D-Sub Connector DIN Rail Mount 2.5A 2962764
Brand: PHOENIX CONTACT
SKU: 201602
Price: 185.77 USD
Availability: InStock



Category D-Sub Connector Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Germany
Voltage	25, 60V ac
Brand	Phoenix Contact
Orientation	Straight
Current	2.5A
Length	156mm
Model	2962764
Depth	45mm
Connector Type	D-Sub
Width	42mm
Gender	Female
Mount Type	DIN Rail
Maximum Operating Temperature	50°C
Minimum Operating Temperature	-20°C
Wire size	16, 26AWG
Number of Contacts	50
Cable CSA	0.14, 1.5mm²
Test Proof Voltage	800V ac

Key Features

Features a 50-contact female D-Sub connector for reliable connections.
Mounted on DIN Rail for easy integration in electrical cabinets.
Supports wire sizes from 16 to 26 AWG with screw connection terminals.
Rated for 2.5A current and test proof voltage of 800V AC.
Operates in temperatures from -20°C to 50°C ensuring stability in varied environments.
Compact design with dimensions of 156mm length, 42mm width, and 45mm depth.
Constructed to reduce cabinet volume and support miniaturisation trends.
High-density configuration suitable for industrial and electronic component assemblies.

Product Description

Phoenix Contact 2962764 is a 50-contact female interface module featuring a D-Sub connector designed for DIN Rail mounting. It supports current up to 2.5A and wire sizes from 16 to 26 AWG via screw connection terminals. This compact interface module is part of the Varioface Compact-Line series, notable for its reduced size and low profile mount of just 45 mm depth, which helps to minimize cabinet volume and costs.

Constructed for robust industrial applications, the module offers a test proof voltage of 800V AC, and operates reliably within a temperature range of -20°C to 50°C. Its length of 156 mm and width of 42 mm suit high-density mounting environments. The straight orientation of the connector ensures straightforward wiring and maintenance.

Ideal for use in industrial automation systems, electronic components configurations, and power connectors, this module supports conductor cross-sections up to 1.5 mm². It is mounted securely on NS 35/7.5 DIN rails, enhancing ease of installation and serviceability.

The product is manufactured in Germany and does not carry additional certifications. It is supplied new and built to meet demanding industrial standards without compromising on reliability or space efficiency.

Features a 50-contact female D-Sub Connector for reliable connections. Mounted on DIN Rail for easy integration in electrical cabinets. Supports wire sizes from 16 to 26 AWG with screw connection terminals. Rated for 2.5A current and test proof voltage of 800V AC.

Operates in temperatures from -20°C to 50°C ensuring stability in varied environments. Compact design with dimensions of 156mm length, 42mm width, and 45mm depth. Constructed to reduce cabinet volume and support miniaturisation trends.

High-density configuration suitable for industrial and electronic component assemblies. Manufactured in Germany with strict quality standards. Explore the Electronics & Electricals category at EnvMart for more industrial-grade connectors and interface modules from reputable manufacturers like Phoenix Contact.
