Cosel Isolated Dual Output DC/DC Converter 30 V dc, -30 V dc, 350 mA Output Current, 18 V - 24 V dc Input, 10.5 W SUTW102415

Cosel SUTW102415 is an isolated dual output DC/DC converter designed to provide stable 30 V dc and -30 V dc outputs with a maximum current of 350 mA. It operates efficiently at 86% and supports input voltages ranging from 18 V to 24 V dc. Packaged in a DIP type PCB mount format, this converter provides high reliability with no built-in electrolytic capacitors, enhancing longevity and performance.

This converter includes features such as adjustable external output voltage with ranges of ±14.25 V dc and ±15.75 V dc, built-in overcurrent protection circuits for safety, and remote ON/OFF control for system flexibility. Its operating temperature range of -40°C to 85°C allows usage in harsh industrial, electronic, and laboratory environments.

The compact size (45.2 mm length, 29.3 mm width and depth), light weight (14 g), and a seven-pin DIP package enable easy installation and integration on PCBs, suitable for power supplies, instrumentation, and control systems. It is cooled by natural convection or forced air to maintain optimal operating temperatures.

Compliant with CE, cUL, EN 60950-1, TUV, and UL 60950-1 standards, this converter ensures safety and performance standards adherence. The isolation voltage of 500 V ac further protects against voltage spikes in power circuits.

Manufactured in Japan, the SUTW series meets rigorous quality and reliability criteria for industrial and commercial use. The PCB mount package with DIP type enables easy integration into electronic assemblies. High efficiency of 86% ensures reliable and energy-saving operation.

Supports an input voltage range from 18 V minimum to 24 V maximum dc. Offers adjustable external output voltage with a ±14.25 V dc and ±15.75 V dc range for precise tuning. Includes built-in overcurrent protection circuits to safeguard the device.

Designed for operating temperatures from -40°C to 85°C suitable for diverse environments. Features 7 pins and isolation voltage of 500 V ac enhancing electrical safety. Compact dimensions of 45.2 mm length, 29.3 mm width and depth fit space-constrained applications.

Manufactured in Japan ensuring high quality and compliance with CE, cUL, EN 60950-1, and TUV standards. Remote ON/OFF functionality and cooling by convection or forced air support flexible system designs.

This product is suitable for industrial electronics, laboratory instrumentation, power supply units, control systems, and HVAC applications where stable isolated dual power outputs are required.
