STMicroelectronics Operational Amplifier 1.4 MHz Gain Bandwidth Product, 6V SOT-23 Package TSV321RILT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | TSV321RILT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | TSV321 |
| Output Current | 80mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1.4MHz |
| Input Bias Current | 150 nA |
| Vos - Input Offset Voltage | 3 mV |
| Slew Rate | 0.6V/μs |
| Input Offset Current | 60 nA |
Key Features
- The op amp is designed for low voltage operation from 3V to 6V supply voltage.
- It has a single channel and a pin count of 5 in a compact SOT-23 surface mount package.
- Input offset voltage is 3 mV with input bias current of 150 nA and input offset current of 60 nA.
- The device supports an output current of 80 mA and has a slew rate of 0.6 V/µs.
- Operating temperature ranges from -40°C to 125°C meeting automotive standard AEC-Q100.
- The amplifier features rail-to-rail input and output capabilities suitable for low voltage applications.
- Typical dimensions are length 3 mm, width 1.75 mm, and height 1.3 mm for compact PCB footprint.
Product Description
STMicroelectronics TSV321RILT Operational Amplifier delivers a gain bandwidth product of 1.4 MHz, optimized for low voltage applications with supply voltages ranging from 3 V to 6 V. This single channel operational amplifier is housed in a compact 5-pin SOT-23 surface mount package, providing an efficient footprint for PCB integration.
This device offers rail-to-rail input and output operation, enabling it to drive loads down to 32 Ω with typical output current up to 80 mA. The input offset voltage is characterized at 3 mV, along with low input bias current of 150 nA and input offset current of 60 nA, ensuring accurate signal amplification in precision analog circuits.
The amplifier features a slew rate of 0.6 V/µs, suitable for moderate speed signal processing tasks. It conforms to automotive quality standards AEC-Q100, allowing usage in automotive and industrial environments with a wide operating temperature range from -40°C to 125°C.
Physical dimensions of this amplifier are 3 mm in length, 1.75 mm in width, and 1.3 mm in height, making it suitable for space-constrained applications. Low voltage rail-to-rail input and output operation supports 3V to 6V power supply.
Compact 5-pin SOT-23 surface mount package for space-efficient PCB design. Single channel operational amplifier with 1.4 MHz gain bandwidth product. Rail-to-rail I/O and output current up to 80 mA for driving low impedance loads.
Input offset voltage of 3 mV, input bias current 150 nA, offset current 60 nA ensure precision. AEC-Q100 automotive compliant for industrial and automotive use. Operating temperature range from -40°C to +125°C.
This Operational Amplifier suits electronic component applications including automotive systems, industrial signal processing, and general-purpose amplification in low voltage environments. Browse the Electronics & Electricals category at EnvMart for compatible components and advanced semiconductor solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TSV321RILT operational amplifier has a gain bandwidth product of 1.4 MHz, making it suitable for various low voltage applications.
This operational amplifier operates with a supply voltage range of 3V to 6V, allowing flexibility in low voltage applications.
The physical dimensions of this operational amplifier are 3 mm in length, 1.75 mm in width, and 1.3 mm in height, making it compact for PCB designs.
It supports an output current of up to 80 mA, enabling it to drive low impedance loads effectively.
The input offset voltage is characterized at 3 mV, which helps in achieving accurate signal amplification.
This model operates within a temperature range of -40°C to 125°C, meeting automotive standards.
The slew rate for the TSV321RILT is 0.6 V/µs, suitable for moderate speed signal processing tasks.
This operational amplifier features a single channel design, making it straightforward for various applications.
The TSV321RILT is housed in a compact SOT-23 surface mount package, which is efficient for PCB integration.
It complies with the AEC-Q100 automotive standard, ensuring its suitability for automotive applications.
The input bias current is specified at 150 nA, contributing to its precision in analog signal processing.
The TSV321RILT is RoHS compliant, indicating it meets environmental standards for hazardous substances in electronic components.
