Crydom Solid State Relay, 50 A Load, Panel Mount, 530 V ac Load Voltage, 32V dc Control MCPC4850D

Crydom MCPC4850D solid state relay is a high-quality single-pole single-throw (SPST) device designed to regulate electrical loads up to 50 A with a maximum load voltage of 530 V AC. It is engineered for panel mounting applications, featuring a compact design with dimensions approximately 45.7 mm in length, 22 mm in width, and 19.8 mm in height. This relay is equipped with SCR output and provides zero voltage switching, which minimizes electrical noise and enhances reliability in industrial control systems.

The MCPC4850D model operates with a control voltage range between 8 V DC and 32 V DC, allowing precise power modulation. Its design includes a screw terminal interface and an IP20 enclosure rating, suitable for indoor panel environments where protection from solid objects is required.

Operating temperature tolerance ranges from -20°C to 80°C, making it suitable for various industrial, automation, and electrical control panel environments such as heating elements, motor speed control, and lamp brightness adjustment. The device provides a portion of each AC sine wave for delivering controlled power to the connected load and includes an output status LED to indicate load open or voltage absence conditions.

The solid state relay's low off-state leakage current (1 mA) and minimal capacitance (8 pF) contribute to efficient power usage and signal integrity. Certified with CE and RoHS standards, the relay meets essential safety and environmental requirements.

The device features a panel mount configuration with screw terminal connections for secure installation. Supports phase angle control for soft start and stop applications that require gradual power ramping. Ideal for use in industrial automation, electrical panels, HVAC control, and manufacturing process controls.

Compact form factor optimizes panel space while maintaining high load capacity. Output status LED enhances monitoring and troubleshooting capabilities. Zero voltage switching reduces electrical noise and extends component life.

Capacitance of 8 pF ensures low reactive interference in control circuits.

Set yourself for reliable power control and enhanced operational efficiency with the Crydom MCPC4850D solid state relay, backed by industry certifications and engineered for demanding industrial applications. Explore more products in the Solid State Relay category at EnvMart for your control and automation needs.
