Legrand Vistop Miniature Circuit Breaker, 4-Pole, 100A, 400V AC/DC, 15 kA Breaking Capacity 0 225 22

Legrand 0 225 22 Miniature Circuit Breaker features a 4-pole design suitable for industrial and commercial electrical installations. Rated at 100 amperes current with both 400 volts AC and DC voltage ratings, it ensures versatile application compatibility in power distribution and automation systems.

This Vistop series circuit breaker incorporates a safety switch disconnector with double break self-cleaning contacts, enabling rapid make and break movements for reliable load switching. The device allows visible isolation with a handle that can be secured in the open position using 1 to 3 padlocks with a 6 mm shackle diameter, augmenting operational safety.

Equipped with cage terminal connections secured by Pz2 screws, it simplifies installation to DIN rails within electrical panels. The assembly complies with prominent standards such as IEC 60947-3, VDE 0113, and NF C 63-130, ensuring conformity with international safety and quality benchmarks. IP ratings ranging between IP20 and IP55 make it resistant to ingress of dust and moisture, suitable for demanding industrial or commercial environments.

The miniature circuit breaker offers a high breaking capacity of 15 kA to effectively protect electrical circuits from overloads and short circuits. Its compact dimensions (125 mm width and 104 mm depth) optimize electrical cabinet space requirements while maintaining full functionality.

Typical applications include power supply protection in industrial manufacturing, HVAC systems, commercial electrical installations, and water treatment plants. This device is engineered for long-term durability and reliable operation under challenging conditions.

Designed for mounting on DIN rail for ease of installation. Supports both AC and DC voltages up to 400V. Provides high breaking capacity of 15 kiloamperes to ensure circuit safety. Equipped with lockable handle allowing 1 to 3 padlocks with 6 mm shackle diameter.

Compact dimensions with 125mm width and 104mm depth optimize panel space. Complies with multiple international standards including IEC and VDE for certified performance. IP ratings range from IP20 to IP55 providing protection against dust and water ingress.

Robust metal and engineered polymer construction for durability in industrial environments. Explore the extensive range of Miniature Circuit Breakers and electrical protection devices available at EnvMart for superior industrial applications.
