KEMET R41 Series Film Capacitor Y2, 100 nF, ±10% Tolerance, 300 V DC 300 V AC, Through Hole Mount R413N310040M1K
Specifications
| Country of Origin | North Macedonia |
|---|---|
| Capacitance Range | 0.001 - 1μF |
| Display | screen |
| Brand | KEMET |
| Height | 17mm |
| Length | 26.5mm |
| Model | R413N310040M1K |
| Packaging | Bag |
| Width | 8.5mm |
| Mount Type | Through Hole |
| Series | R41 |
| Maximum Operating Temperature | 110°C |
| Tolerance | ±10 % |
| Capacitance | 100nF |
| Minimum Operating Temperature | -40°C |
| Climatic category | 40/110/56,IEC60068 - 1 |
| Terminal type | Radial |
| Dissipation Factor | 0.3% |
| Lead Length | 30mm |
| Pin Count | 2 |
| Rated AC Voltage | 300V ac |
| Rated DC Voltage | 300V dc |
| Lead Pitch | 22.5mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Suppression Class | Y2 |
| Capacitance tolerance | ±20%,±10% |
| Lead Spacing | 10 - 37.5mm |
Key Features
- This metallized polypropylene film capacitor features self-healing properties for enhanced reliability.
- Designed for electromagnetic interference (EMI) suppression in line-to-ground and across-the-line filter applications.
- Offers a lead pitch of 22.5 mm with radial terminal type and through hole mounting.
- Operates within temperature range from -40°C to 110°C ensuring stable performance.
- Has a dissipation factor of 0.3% and meets automotive AEC-Q200 standards.
- Complies with UL 60384-14, EN/IEC 60384-14, and CAN/CSA E60384-14 safety standards.
- Suitable for industrial, electronic manufacturing, and power supply EMI suppression uses.
- Supplied in bag packaging with pin count of 2 and lead length of 30 mm.
Product Description
KEMET R413N310040M1K Film Capacitor Y2 is a metallized polypropylene film capacitor intended for EMI suppression and safety applications. It has a capacitance of 100 nF with a tolerance of ±10%, rated for 300 V DC and 300 V AC voltage. This capacitor includes self-healing features to maintain functionality during electrical stress and extends the overall operational life.
The capacitor is designed with a through hole mount and radial terminals spaced 22.5 mm apart, fitting a wide range of industrial and electronic circuit boards. It operates effectively across the temperature range from -40°C to 110°C, suitable for demanding environments.
Typical uses include interference suppression in line-to-ground and across-the-line applications where Y2 safety classification is required, commonly found in power supply filters and consumer appliances. The R41 series capacitors also comply with stringent automotive AEC-Q200 standards, making them reliable for automotive electronics.
The physical dimensions include a length of 26.5 mm, width of 8.5 mm, and height of 17 mm, with lead length 30 mm and diameter 0.8 mm. The dissipation factor is rated at 0.3%, ensuring low energy loss during operation.
Self-healing metallized polypropylene film construction ensures durability and safety. Certified under UL 60384-14, EN/IEC 60384-14, and CAN/CSA E60384-14 standards for quality and safety. Capacitance tolerance maintains consistent performance in precise circuits.
Capable of handling 300 V DC and AC voltages with automotive-grade reliability. Wide operating temperature range suitable for industrial and automotive environments. Radial lead design allows easy through-hole PCB mounting.
Comes packaged in bags for bulk handling and assembly.
This capacitor is ideal for electromagnetic interference filtering in industrial, automotive, electronics manufacturing, and power electronics applications. Its robust specification ensures it meets demanding safety and performance criteria. Browse our complete selection of Film Capacitors for diverse industrial electronics needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 100 nF with a tolerance of ±10%.
It is rated for 300 V DC and 300 V AC voltage applications.
The operating temperature range is from -40°C to 110°C.
The dissipation factor is rated at 0.3%, ensuring low energy loss during operation.
It features a through hole mount with radial terminals.
The dimensions are 26.5 mm in length, 8.5 mm in width, and 17 mm in height.
The lead length is 30 mm with a diameter of 0.8 mm.
It complies with UL 60384-14, EN/IEC 60384-14, and CAN/CSA E60384-14 safety standards.
It is suitable for electromagnetic interference (EMI) suppression in industrial, automotive, and power supply applications.
This capacitor has a pin count of 2 and a lead pitch of 22.5 mm.
It meets the automotive AEC-Q200 standard, ensuring reliability for automotive electronics.
The country of origin for this capacitor is North Macedonia.
