JAE MIL Spec Circular Connector Copper Alloy Straight 17 Way Cable Connector Male 500V 44.2A Shell Size 20 N/MS3106B20-29S
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 500V |
| Brand | JAE |
| Colour | Black |
| Orientation | Straight |
| Current | 44.2A |
| Model | N/MS3106B20-29S |
| Mount Type | Cable |
| Housing Material | Zinc |
| Contact Material | Copper Alloy |
| Series | N/MS |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Contact Plating | Silver |
| Number of Contacts | 17 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 20 |
| Military Standard | MIL-5015 |
| Connector Size | Standard |
| Shell Plating | Zinc |
Key Features
- Complies with MIL-5015 military standard for reliable performance.
- Connector has a straight orientation with male connector gender.
- Housing made of zinc with black color and zinc shell plating for durability.
- Contacts are made from silver plated copper alloy, ensuring excellent conductivity.
- Suitable for cable mount with solder termination for secure connections.
- Operates reliably in temperature ranges from -30°C to 85°C.
- Standard sized connector designed for industrial and military applications.
- Designed for a voltage rating of up to 500 volts and a current rating of 44.2 amperes.
Product Description
JAE N/MS3106B20-29S Mil Spec Circular Connector is a high-quality cable connector designed to meet MIL-5015 military specifications. It features 17 female contacts housed in a durable zinc shell with black finish. The connector has a straight orientation and is designed with a male connector gender suitable for cable mounting with solder termination.
Constructed with copper alloy contacts plated with silver, this connector offers excellent electrical conductivity and corrosion resistance. The zinc housing and zinc plated shell provide mechanical strength and environmental protection, making it suitable for demanding industrial, military, and aerospace applications.
This MIL Spec connector supports an operational voltage of 500 volts and a maximum current of 44.2 amperes, ensuring reliable performance under high electrical loads. It can operate within extreme temperatures ranging from -30°C to 85°C, making it versatile for harsh environments.
Its standard shell size 20 and footprint comply with established military connector standards, ensuring compatibility with a broad range of electronic systems. The product is manufactured in Japan and is ideal for use in electronics, aerospace, industrial machinery, and military equipment.
Complies with MIL-5015 military standard for reliable performance. Connector has a straight orientation with male connector gender. Housing made of zinc with black color and zinc shell plating for durability. Contacts are made from silver plated copper alloy, ensuring excellent conductivity.
Suitable for cable mount with solder termination for secure connections. Operates reliably in temperature ranges from -30°C to 85°C. Standard sized connector designed for industrial and military applications. Designed for a voltage rating of up to 500 volts and a current rating of 44.2 amperes.
This JAE circular connector is perfect for demanding applications in industrial controls, aerospace systems, military hardware, and any environment requiring MIL-Spec compliant connectors. Browse EnvMart for a wide selection of high-quality circular connectors and related accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is designed for a voltage rating of up to 500 volts and a current rating of 44.2 amperes.
The housing is made of zinc, while the contacts are constructed from silver plated copper alloy, ensuring excellent conductivity and corrosion resistance.
It operates reliably in temperature ranges from -30°C to 85°C, making it suitable for harsh environments.
This connector features 17 female contacts, designed for secure connections.
It is suitable for cable mount with solder termination, providing secure connections for various applications.
The connector has a standard shell size of 20, complying with established military connector standards.
The connector has a straight orientation with a male connector gender.
Yes, it complies with the MIL-5015 military standard, ensuring reliable performance in demanding applications.
This connector is manufactured in Japan.
It is designed for use in industrial controls, aerospace systems, military hardware, and other environments requiring MIL-Spec compliant connectors.
The housing is black in color, providing a distinct appearance for identification.
The zinc housing and zinc plated shell provide mechanical strength and environmental protection, making it suitable for demanding conditions.
