JAE Mil Spec Circular Connector Copper Alloy Straight 3 Way Cable Male Female Contacts 500V 13A Shell Size N/MS3106B14S-7S
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 500V ac |
| Brand | JAE |
| Colour | Black |
| Orientation | Straight |
| Current | 13A |
| Model | N/MS3106B14S-7S |
| Mount Type | Cable |
| Housing Material | Zinc |
| Contact Material | Copper Alloy |
| Series | N/MS |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Contact Plating | Silver |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 14S |
| Military Standard | MIL-5015 |
| Connector Size | Standard |
| Shell Plating | Zinc |
Key Features
- The connector features a black zinc housing with silver-plated copper alloy female contacts for enhanced conductivity.
- It complies with MIL-5015 military standard ensuring high reliability in industrial and military environments.
- Designed for operation in temperatures from -30°C up to 85°C.
- Features a standard size 14S shell with straight orientation and solder termination type.
- The robust zinc plating on shell and housing offers durable corrosion resistance.
- Suitable for industrial, aerospace, military, and electronic component applications requiring high-quality circular connectors.
Product Description
The JAE N/MS3106B14S-7S Mil Spec Circular Connector is a high-performance electrical connector designed for demanding industrial and military applications. This copper alloy 3-way connector features female contacts, a male connector gender, and a straight cable mount orientation, making it ideal for secure and reliable cable connections.
Operating at 500V AC voltage and 13A current, it provides robust electrical performance in harsh environments. The shell size 14S along with zinc housing and plating offers mechanical strength and corrosion protection, critical for long service life in field conditions.
Its construction adheres to the MIL-5015 military standard, ensuring it meets stringent specifications for durability and reliability under extreme temperature ranges from -30°C to 85°C. The solder termination type facilitates straightforward assembly, and the standard connector size simplifies system integration.
This connector is well suited for use in industrial machinery, aerospace electronics, military communication systems, and other applications needing rugged circular connectors with excellent electrical and mechanical characteristics.
The connector has a black zinc shell color for easy identification and enhanced aesthetic compatibility. Silver plating on copper alloy contacts ensures excellent conductivity and corrosion resistance. The straight orientation supports efficient cable routing and connection integrity.
Designed for cable mount type installation improving versatility in wiring setups. Compliance with MIL-5015 ensures industry-standard mechanical and electrical specifications.
JAE connectors are recognized for their quality and reliability, making this model a trusted choice for critical applications. Explore the extensive range of Mil Spec Circular Connectors by JAE to find matching components and accessories for complete connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a voltage of 500V AC and a current of 13A.
The connector can operate in temperatures ranging from -30°C to 85°C.
It features a solder termination type, facilitating straightforward assembly.
This model has a standard shell size of 14S.
The housing is made of zinc, and the contacts are copper alloy with silver plating for enhanced conductivity.
It has a straight orientation, which supports efficient cable routing and connection integrity.
It complies with the MIL-5015 military standard, ensuring high reliability in demanding environments.
This connector features female contacts and a male connector gender.
It is suitable for industrial machinery, aerospace electronics, military communication systems, and other applications requiring rugged circular connectors.
The shell has a black zinc color for easy identification and aesthetic compatibility.
It supports cable mount type installation, improving versatility in wiring setups.
The connector is manufactured in Japan.
