TE Connectivity 12-Way IDC Female Connector with Nylon Housing 3.96mm Pitch Cable Mount 7A 600V AC 4-640426-2

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity 12-Way IDC Female Connector with Nylon Housing 3.96mm Pitch Cable Mount 7A 600V AC 4-640426-2

Name: TE Connectivity 12-Way IDC Female Connector with Nylon Housing 3.96mm Pitch Cable Mount 7A 600V AC 4-640426-2
Brand: TE Connectivity
SKU: 195210
Price: 1.73 USD
Availability: InStock



Category IDC Connector Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	600V ac
Brand	TE Connectivity
Orientation	Right Angle
Current	7A
Mount Type	Cable
Housing Material	Nylon
Contact Material	Copper
Series	MTA-156
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	3.96mm
Contact Plating	Tin over Nickel
Number of Contacts	12
Contact Gender	Female
Connector Gender	Female
Shrouded/Unshrouded	Shrouded

Key Features

Features a shrouded design with right angle orientation for cable mounting.
Supports up to 12 contacts in a single row configuration.
IDC termination type allows efficient insulation displacement contact assembly.
Constructed with copper contacts plated with tin over nickel for durability.
Housing made of nylon 6/6 with moulded ribs to prevent reverse mating.
Suitable operating temperature range from -55°C to 105°C for reliable performance.
Complies with MTA-156 series connector system standards.
Designed to accept stranded wires sized 18 to 26 AWG.

Product Description

TE Connectivity 4-640426-2 is a high-quality 12-way IDC female connector designed for cable mounting with a 3.96mm pitch spacing and a current rating of 7A at 600V AC. This connector features a shrouded nylon housing made of UL94V-2 nylon 6/6 with molded ribs to prevent improper mating, ensuring secure and reliable connections in demanding industrial and electronic applications.

The termination method uses Insulation Displacement Contact (IDC) technology, enabling quick and efficient assembly without the need for wire stripping, compatible with stranded discrete wires ranging from 18 to 26 AWG. The connector’s contacts are made from copper and plated with tin over nickel, providing durability and corrosion resistance under typical operating environments.

It supports a right angle orientation and cable mount type, making it suitable for wire-to-wire and wire-to-board connections in electronics manufacturing, industrial automation, and other wire harness assembly tasks. This MTA-156 series connector complies with relevant quality standards, providing a reliable solution for high-density cable interconnections.

The operating temperature of this connector ranges from -55°C to 105°C, making it suitable for diverse environmental conditions found in industrial, manufacturing, laboratory, and commercial applications. The compact female IDC design simplifies mass termination assemblies, saving time and reducing labor costs.

Features a shrouded design with right angle orientation for cable mounting. Supports up to 12 contacts in a single row configuration. IDC termination type allows efficient insulation displacement contact assembly. Constructed with copper contacts plated with tin over nickel for durability.

Housing made of nylon 6/6 with moulded ribs to prevent reverse mating. Suitable operating temperature range from -55°C to 105°C for reliable performance. Complies with MTA-156 series connector system standards. Designed to accept stranded wires sized 18 to 26 AWG.

Voltage rating up to 600V AC ensures robust insulation. Applications include electronics manufacturing, industrial automation, and wiring harness assembly.

This TE Connectivity MTA-156 12-way IDC Connector is an ideal choice for optimizing wire termination processes in electronics, industrial automation, and wiring applications. Explore a wide range of TE Connectivity products on EnvMart for reliable interconnect solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The connector has a voltage rating of 600V AC, ensuring robust insulation for various applications.

It has a current rating of 7A, making it suitable for a variety of electrical applications.

The operating temperature range is from -55°C to 105°C, allowing it to perform reliably in diverse environmental conditions.

This model utilizes Insulation Displacement Contact (IDC) technology, which allows for quick and efficient assembly without the need for wire stripping.

The pitch size of this IDC female connector is 3.96mm, which is standard for many electronic applications.

The housing is made of nylon 6/6, and the contacts are constructed from copper plated with tin over nickel for durability and corrosion resistance.

It supports up to 12 contacts in a single row configuration, facilitating efficient connections in various applications.

The connector features a right angle orientation, which is beneficial for space-constrained installations.

It is designed to accept stranded wires sized from 18 to 26 AWG, making it versatile for different wiring needs.

Yes, it complies with the MTA-156 series connector system standards, ensuring quality and reliability in its applications.

The connector is manufactured in India, reflecting its origin in quality production standards.

It is suitable for electronics manufacturing, industrial automation, and wiring harness assembly, providing reliable interconnections in these fields.
