XP Power CA High Voltage DC/DC Converter 200V, 2000V Output, 15.5V Input, 1W Power, Chassis Mount, CA20P-5
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power CA DC/DC Converter, 200V, 2000 V/, 15 |
| Brand | XP Power |
| Length | 44.45mm |
| Model | CA20P-5 |
| Depth | 0.5in |
| Gross Weight | 39.6g |
| Width | 27.94mm |
| Mount Type | Chassis |
| Series | CA |
| Maximum Operating Temperature | 50°C |
| Package Type | Miniature Shielded Case |
| Minimum Operating Temperature | -10°C |
| MTBF | 2100000h |
| Number of outputs | 1 |
| Ripple and Noise | 0.001% Pk-Pk |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 15.5V |
| Standards/Approvals | UL, UL1950, RoHS |
| Minimum Input Voltage | 4.75V |
| Number of Pins | 8 |
| Output Voltage 1 | 200, 2000V |
| Output Current 1 | 5mA |
Key Features
- Operates from a wide input voltage range of 4.75V to 15.5V.
- Delivers a maximum output power of 1 watt with low ripple and noise at 0.001% Pk-Pk.
- Features a chassis mounting type with a miniature shielded case package.
- Supports a maximum output current of 5 mA and includes an 8-pin configuration.
- Built to operate within temperatures from -10 °C up to 50 °C for reliable performance.
- Complies with UL 1950 and RoHS standards for safety and environmental compliance.
- Designed with a precision onboard reference and easy calibration adjustment access.
- Ideal for applications including photomultiplier tubes, solid-state detectors, electrophoresis, and capacitor charging.
Product Description
XP Power CA20P-5 is a high-performance, high-voltage DC/DC converter designed for precision and reliability in industrial and laboratory settings. This chassis-mounted converter provides dual output voltages of 200V and 2000V with a maximum power rating of 1 watt, suitable for sensitive electronic applications.
It operates efficiently within a broad input voltage range from 4.75V minimum to 15.5V maximum, ensuring adaptability across various power sources. The miniature shielded case design offers excellent EMI/RFI suppression alongside low noise levels, delivering ripple and noise as low as 0.001% Pk-Pk. The converter includes eight pins for secure electrical connections and supports a steady output current of 5 mA.
Constructed with durability in mind, the XP Power CA20P-5 withstands operating temperatures from -10 °C up to 50 °C, facilitating usage in challenging environments. Its robust shielded chassis mounted package enhances mechanical stability and electromagnetic compatibility.
The device is precision regulated with a high-level stability, featuring a voltage monitor and readback capabilities. Its sealed converter enclosure withstands immersion cleaning processes, extending service life. Calibration and potentiometer adjustments ease fine-tuning for specific application needs.
Common industrial and scientific applications include powering photomultiplier tubes, avalanche photodiodes, solid-state detectors, electrophoresis equipment, EO lenses, piezo devices, and capacitor charging units. Compliance with UL 1950 and RoHS directives confirms the product’s safety and environmental conformity.
Operates from a wide input voltage range of 4.75V to 15.5V. Maximum output power of 1 watt with low ripple and noise. Chassis mount with miniature shielded case package. Output current rating of 5 mA with 8-pin configuration.
Temperature range from -10 °C to 50 °C for diverse environments. Certified with UL 1950 and RoHS standards. Precision regulated with calibration and voltage monitoring. Sealed design suitable for immersion cleaning processes.
This XP Power DC/DC converter is ideal for industrial, laboratory, and scientific power supply needs requiring precise, stable high voltage outputs. Explore more DC/DC Converters and power supply solutions at EnvMart to find the perfect fit for your electrical design and manufacturing projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates from a wide input voltage range of 4.75V to 15.5V.
The maximum output power is 1 watt.
This model provides dual output voltages of 200V and 2000V.
It supports a maximum output current of 5 mA.
It can operate within temperatures from -10 °C up to 50 °C.
It features a chassis mounting type.
The ripple and noise level is as low as 0.001% Pk-Pk.
This model includes an 8-pin configuration.
It complies with UL 1950 and RoHS standards.
The gross weight of this unit is 39.6 grams.
It is ideal for applications including photomultiplier tubes, solid-state detectors, and electrophoresis equipment.
It comes in a miniature shielded case package.
