Relpol PCB Power Relay 24V AC Coil 12A Switching Current SPDT RM87N-2011-35-5024

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay 24V AC Coil 12A Switching Current SPDT RM87N-2011-35-5024

Name: Relpol PCB Power Relay 24V AC Coil 12A Switching Current SPDT RM87N-2011-35-5024
Brand: Relpol
SKU: 191755
Price: 8.47 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	15.7mm
Length	29mm
Model	RM87N-2011-35-5024
Width	12.7mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM87
Maximum Operating Temperature	70°C
Contact Configuration	SPDT
Minimum Operating Temperature	-40°C
Switching Current	12A
Terminal type	Plug-In
Contact Resistance	100mΩ
Standards/Approvals	EAC, RoHS
Coil Resistance	400Ω
Coil Voltage	24V ac
Switching DC Voltage	24V dc
Switching AC Voltage	440V
Coil Power	750mW

Key Features

Designed for PCB mounting with a plug-in terminal type for easy installation.
Features a silver alloy contact material ensuring high conductivity and low contact resistance.
Operates across a temperature range of -40°C to 70°C for robust industrial performance.
Supports switching voltages up to 440V AC and 24V DC with 3kVA switching power capacity.
Compact dimensions with length 29mm, width 12.7mm, and height 15.7mm suitable for miniature applications.
Coil resistance is 400 Ω with coil power dissipated at 750mW.
Meets EAC and RoHS standards, ensuring environmental and safety compliance.
Manufactured in Poland, ensuring high-quality European production standards.

Product Description

Relpol RM87N-2011-35-5024 PCB Power Relay is designed for industrial and commercial applications requiring reliable switching. This power relay operates with a 24V AC coil voltage and supports a switching current of 12A in a Single Pole Double Throw (SPDT) contact configuration. It is intended for PCB mounting and features a plug-in terminal type that facilitates quick and secure installation.

The relay's compact size, measuring 29mm in length, 12.7mm in width, and 15.7mm in height, makes it ideal for miniature and space-constrained setups. It uses silver alloy contacts to deliver consistent electrical conductivity and minimize contact resistance (100mΩ), enhancing overall reliability and efficiency. The coil resistance is 400Ω with an operating coil power of 750mW, allowing for energy-efficient operation.

Built to withstand a minimum operating temperature of -40°C and a maximum of 70°C, this relay can perform reliably in harsh environments. It supports switching voltages up to 440V AC and 24V DC with a maximum switching power of 3kVA, suitable for a wide range of automation, control, and electrical circuit applications.

Compliance with EAC and RoHS standards confirms adherence to environmental safety and product quality norms. The relay is made in Poland, reflecting stringent manufacturing processes and quality assurance for industrial reliability.

This PCB power relay is suited for use in industrial automation, electrical equipment, manufacturing machinery, HVAC systems, and other control systems requiring precise and dependable relay operation.

Designed for PCB mounting with plug-in terminals for easy installation. Silver alloy contacts ensure high conductivity and low resistance. Operates effectively at temperatures from -40°C to 70°C. Supports switching voltages up to 440V AC and DC switching up to 24V.

Compact dimensions benefit space-limited applications. Coil resistance and power ratings engineered for efficient performance. RoHS compliant and meets EAC standards for quality assurance. Manufactured in Poland for high-quality industrial reliability.
