Ewellix Makers in Motion Linear Guide Carriage Slimline 20 mm Rail Width 15.2 kN Dynamic Load LLTHC 20 LR T0 P5

Ewellix Makers in Motion LLTHC 20 LR T0 P5 linear guide carriage is a high-precision mechanical component optimized for linear motion applications in industrial automation, manufacturing, and mechanical systems. Featuring a slimline carriage design compatible with 20 mm wide rails, it supports a dynamic load of 15.2 kN and a static load of 32.7 kN, making it suitable for demanding operational environments requiring high accuracy and durability.

The carriage integrates side and inner seals as standard, providing protection against dust and contaminants to enhance lifespan and reliability. Its design incorporates equal load carrying capacity with superior top rigidity, ensuring stable linear movement even under significant loading. Rails are manufactured with dual reference sides and exhibit low surface roughness for minimal friction and wear.

This product offers excellent performance while occupying minimal installation space, making it ideal for compact machine designs. The low-friction characteristics support smooth running on high-quality surfaces, reducing maintenance needs and extending operational life. Installation and adjustment are simplified by the carriage’s mounting threads on the top side, which accommodate easy fastening.

The long, slim-line carriage profile with increased height further reinforces structural rigidity, enhancing load support capabilities. The size range for this series extends from 15 to 45, allowing selection based on application requirements. This product is manufactured in Taiwan, Province Of China, adhering to recognized quality standards.

Typical industrial applications include automation equipment, CNC machinery, robotics, and precision assembly systems where accurate and reliable linear motion is crucial. The LLTHC 20 LR T0 P5 carriage is designed to integrate easily within existing mechanical assemblies, providing long-term, stable, and high-performance operation.

Set contains 1 Pc Ewellix Makers in Motion Linear Guide Carriage LLTHC 20 LR T0 P5. Explore the wide range of mechanical motion components in the Linear Guide Blocks category at EnvMart for compatible rails and accessories.

Includes integrated side and inner seals within the carriage for protection against contaminants. Equal load carrying capacity combined with enhanced top rigidity ensures durability. Rails include dual reference sides with low surface roughness for smooth operation.

High performance is achieved relative to the compact spatial requirements. Low friction and wear ensure smooth running on high-quality surfaces. Easy installation and adjustment with low maintenance needs. Carriage has a long, slim-line design with extended height for improved rigidity.

Equipped with four threads for mounting from the top side. Manufactured in Taiwan, Province Of China, ensuring product quality standards.
