Relpol Miniature PCB Power Relay 5V DC Coil, 16A Switching Current, 1 CO Contact RM85-2011-35-1005
Specifications
| Country of Origin | Poland |
|---|---|
| Brand | Relpol |
| Height | 15.7mm |
| Length | 29mm |
| Model | RM85-2011-35-1005 |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | RM85 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | 1 CO |
| Minimum Operating Temperature | -40°C |
| Switching Current | 16A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | EAC, RoHS |
| Coil Resistance | 60Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 24V dc |
| Switching AC Voltage | 24V ac |
| Coil Power | 480mW |
Key Features
- Compact RM85 series miniature design suitable for PCB mounting.
- Operates with a 5V DC coil voltage and 60 Ω coil resistance.
- Switching capabilities include 16A current with up to 24V AC/DC voltage rating.
- Contact material made from silver alloy ensuring low contact resistance of 100 mΩ.
- Wide operating temperature range from -40°C to 85°C for industrial environments.
- Coil power consumption rated at 480 mW enabling low power operation.
- Complies with RoHS and EAC standards for environmental compliance.
- Designed with PCB pin terminals for secure and easy mounting.
Product Description
Relpol RM85-2011-35-1005 is a miniature power relay designed for industrial and general-purpose PCB mounting applications. It features a 5V DC coil voltage and a single pole double throw (1 CO) contact configuration, enabling reliable switching of loads up to 16A.
The relay operates at switching voltages of 24V AC/DC and withstands temperatures ranging from -40°C to 85°C, ensuring durability across various environmental conditions. Its silver alloy contacts provide excellent conductivity and low resistance, measured at 100 milliohms.
The compact dimensions of 29 mm in length, 12.7 mm in width, and 15.7 mm in height allow for efficient use of PCB space in industrial control systems, automation, HVAC, and manufacturing equipment.
The coil resistance of 60 ohms and low coil power consumption of 480 mW contribute to energy-efficient operation. Terminals are designed as PCB pins for easy integration in circuit boards.
Compact RM85 series miniature design suitable for PCB mounting. Operates with a 5V DC coil voltage and 60 Ω coil resistance. Switching capabilities include 16A current with up to 24V AC/DC voltage rating. Contact material made from silver alloy ensuring low contact resistance of 100 mΩ.
Wide operating temperature range from -40°C to 85°C for industrial environments. Dimensions: 29 mm length, 12.7 mm width, and 15.7 mm height for space-efficient installation. Coil power consumption rated at 480 mW enabling low power operation.
Complies with RoHS and EAC standards for environmental compliance. Designed with PCB pin terminals for secure and easy mounting.
This relay is suitable for use in electrical automation, industrial machinery control, signal conditioning, HVAC systems, and other commercial applications requiring reliable switching performance.
Browse the Electronics & Electricals category on EnvMart for more Power Relay options and advanced industrial control components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a coil voltage of 5V DC.
It can handle a maximum switching current of 16A.
The dimensions are 29 mm in length, 12.7 mm in width, and 15.7 mm in height.
This relay features a single pole double throw (1 CO) contact configuration.
The operating temperature range is from -40°C to 85°C.
The contact material is made from silver alloy, ensuring low contact resistance.
The coil resistance is rated at 60 ohms.
The coil power consumption is rated at 480 mW.
It can switch voltages of up to 24V AC and 24V DC.
This relay is designed for PCB mounting with PCB pin terminals.
It complies with RoHS and EAC standards for environmental compliance.
It is suitable for use in electrical automation, industrial machinery control, signal conditioning, and HVAC systems.
