Fagor Electronica 1-Element Uni-Directional TVS Diode 400 W 2-Pin DO-214AC P4SMA39A

Fagor Electronica P4SMA39A is a premium quality 1-element uni-directional TVS diode designed to protect electronic circuits from transient voltage spikes. Rated at 400 W peak pulse power dissipation, this diode features a compact 2-pin DO-214AC surface mount package ideal for space-constrained applications.

The diode configuration is single, optimized for uni-directional transient voltage suppression with a minimum breakdown voltage of 37.1 V and maximum reverse stand-off voltage of 33.3 V. It offers a clamping voltage of 53.9 V and can handle a maximum peak pulse current of 7.8 A, ensuring robust circuit protection against voltage surges.

Constructed for reliability, the P4SMA39A operates efficiently within temperatures ranging from -65°C up to 150°C, making it suitable for industrial, automotive, and electronic manufacturing environments requiring durable and reliable transient voltage suppression solutions.

The device is surface mount type with package dimensions measuring 5.1 mm in length, 2.6 mm in width, and 2 mm in height. Its low maximum reverse leakage current of 1 μA adds to system efficiency by minimizing power loss.

This TVS diode does not incorporate ESD protection and contains a single element per chip. It is part of the P4SMA series from Fagor Electronica and is manufactured in Thailand, reflecting high production and quality standards.

This diode features a single diode configuration for transient voltage suppression. It supports a minimum breakdown voltage of 37.1 V and maximum reverse stand-off voltage of 33.3 V. The package is surface mount type with dimensions of 5.1 mm length, 2.6 mm width, and 2 mm height.

The maximum peak pulse current rating is 7.8 A with a clamping voltage of 53.9 V. Operating temperature ranges from -65°C to 150°C for reliable performance in harsh environments. It has low reverse leakage current of 1 μA ensuring efficient protection.

Designed for surface mount applications with 2 pins in DO-214AC (SMA) packaging. Manufactured in Thailand ensuring adherence to quality standards.

This TVS diode is widely used in electronic manufacturing, industrial equipment, power supplies, automotive electronics, and PCB assemblies where transient voltage suppression is critical to protect sensitive components and ensure system reliability.
