TE Connectivity VAL-U-LOK Series Straight Through Hole PCB Header, 20 Contacts, 4.2 mm Pitch, 2 Row, Shrouded 2-1586037-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 9A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | VAL-U-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- The connector system supports wire-to-board connection with positive latching.
- Contacts are made of brass with tin plating ensuring reliable conductivity.
- Designed for 600V and 9A current rating ensuring robust performance.
- Housings are made from UL94V-2 rated nylon for safety and durability.
- Compatible with solder termination and provides 3.5 mm tail pin length for secure PCB attachment.
- Operating temperature range from -40°C to 105°C suits various industrial environments.
- The connector has a straight orientation and is shrouded to prevent accidental contact.
- Ideal for electronic, industrial, and manufacturing applications requiring stable PCB connections.
Product Description
TE Connectivity 2-1586037-0 VAL-U-LOK Series Straight Through Hole PCB Header with 20 male contacts offers a 4.2 mm pitch in a 2-row, shrouded design. It features a wire-to-board connector system with positive latching and keying for accurate alignment during mating. The connector is constructed with brass contacts plated in tin and housed in UL94V-2 rated nylon material, providing durability and safety in electronic assemblies.
Designed for mounting on printed circuit boards (PCBs) through a through-hole technique, this header supports a current rating of 9A and a voltage of up to 600V. The tail pin length of 3.5 mm and solder termination ensure robust electrical and mechanical connection. Its operating temperature range from -40°C to 105°C makes it adaptable to diverse industrial environments.
This VAL-U-LOK series connector suits applications in industrial automation, electronic equipment manufacturing, and PCB assembly where secure, reliable, and easy-to-mate connections are imperative. Its shrouded construction enhances user safety by preventing exposure to the contacts.
The product is well-suited for high-density PCB designs requiring double row connectivity and features pegs for PCB alignment and mounting. It ensures a stable and precise electronic connection with its male contact gender and shrouded housing.
The connector supports positive latching and keying for secure mating. Housing material is UL94V-2 rated nylon providing flame resistance. Brass contacts with tin plating deliver excellent conductivity. Through-hole mount type enables stable PCB attachment.
Operating voltage is rated at 600V with 9A current capability. The connector operates reliably across -40°C to 105°C temperature range. Tail pin length of 3.5 mm supports solder termination. Double row, 20 contact design allows high-density connections.
Shrouded design ensures user safety by preventing accidental contact.
Explore EnvMart’s extensive electronics components range for reliable connectors like the TE Connectivity VAL-U-LOK Series. Suitable for diverse industrial, manufacturing, and electronics assembly applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for a maximum operating voltage of 600V.
It supports a current rating of 9A.
This model features a pitch size of 4.2 mm.
The connector has 20 male contacts.
It utilizes solder termination for secure connections.
The tail pin length is 3.5 mm, which supports secure PCB attachment.
The contacts are made of brass with tin plating, and the housing is constructed from UL94V-2 rated nylon.
It operates reliably within a temperature range of -40°C to 105°C.
Yes, it is designed for through-hole mounting on printed circuit boards (PCBs).
The shrouded design prevents accidental contact with the contacts, enhancing user safety.
It is suitable for industrial automation, electronic equipment manufacturing, and PCB assembly applications.
This connector is part of the VAL-U-LOK series by TE Connectivity.
