XP Power Isolated DC/DC Converter 12V DC 250mA 9V/4.5V Input 6W Through Hole JCA0605D02
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCA DC/DC Converter, 12V dc/ 250 mA, 9V d |
| Brand | XP Power |
| Efficiency | 83% |
| Length | 25.4mm |
| Model | JCA0605D02 |
| Depth | 10mm |
| Width | 20.3mm |
| Mount Type | Through Hole |
| Series | JCA |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1000000h |
| Number of outputs | 2 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 9V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 24 |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 250mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Compact DIP package with Through Hole mount for PCB integration.
- High isolation voltage of 1.5kV DC between input and output.
- Operating temperature range from -40°C to 100°C for versatile applications.
- Efficiency rated at approximately 83% ensuring low power loss.
- Suitable for industrial and electronic component power supply uses.
- MTBF rated at 1,000,000 hours for high reliability.
- Standard 24-pin configuration and industry standard pinout.
- Package dimensions approximately 25.4mm length, 20.3mm width, and 10mm depth.
Product Description
XP Power JCA0605D02 is an isolated DC/DC converter designed for power and electronic applications requiring a reliable 12V DC output at 250mA. The converter supports input voltages ranging from 4.5V minimum up to 9V maximum with a 2:1 input voltage ratio, delivering up to 6W output power.
Its compact DIP through-hole package measures 25.4mm by 20.3mm with a depth of 10mm, facilitating easy insertion into machinery and electronics with an industry-standard 24-pin layout. The converter provides excellent isolation with 1.5kV DC between input and output, suitable for sensitive electronic circuits needing noise isolation and protection.
The device operates efficiently at 83%, minimizing heat generation and improving energy management. It endures extreme temperature conditions from -40°C to +100°C, making it ideal for harsh industrial environments, electronics manufacturing, and power supply applications.
This model boasts a mean time between failures (MTBF) of 1,000,000 hours, supporting high reliability and long operational life, essential in industrial, laboratory, HVAC, and manufacturing settings.
Being made in Taiwan, it complies with UL and TUV standards, ensuring quality assurance and safety compliance. It is suitable for use in power supplies, isolated voltage conversion, and works well in industrial electronics.
Compact DIP through-hole mounting package. Isolated 12V DC output at 250mA current. Input voltage range 4.5V to 9V DC with 2:1 input ratio. High isolation voltage of 1.5kV DC input to output. Operating temperature range of -40°C to 100°C.
Efficiency rating of 83% for reduced power loss. Reliable with 1,000,000 hours MTBF. Industry-standard 24-pin configuration. Manufactured in Taiwan with UL and TUV approvals.
Explore this DC/DC Converter to enhance power management solutions in electronics, industrial equipment, and control systems. Discover more reliable industrial electronics at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an output voltage of 12V DC with a maximum output current of 250mA.
The input voltage range for this converter is from 4.5V to 9V DC, with a 2:1 input voltage ratio.
It has an efficiency rating of approximately 83%, which helps minimize power loss during operation.
The package dimensions are approximately 25.4mm in length, 20.3mm in width, and 10mm in depth.
It features a high isolation voltage of 1.5kV DC between the input and output.
The operating temperature range is from -40°C to 100°C, making it suitable for harsh environments.
This converter has a mean time between failures (MTBF) rated at 1,000,000 hours, indicating high reliability.
It utilizes a through-hole mounting type, designed for easy PCB integration.
This model features a standard 24-pin configuration, adhering to industry standards.
It is suitable for industrial and electronic component power supply applications, as well as isolated voltage conversion.
This unit is manufactured in Taiwan and complies with UL and TUV standards for quality assurance.
The maximum output power of this model is 6W, providing sufficient power for various applications.
