XP Power IE Series DC/DC Converter, 24V DC Output, 40mA, 26.4V DC Max Input, 21.6V Min Input, 1W Power, Through IE2424S
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power IE DC/DC Converter, 24V dc/ 40 mA, 26 |
| Brand | XP Power |
| Efficiency | 80% |
| Length | 11.68mm |
| Model | IE2424S |
| Depth | 10.15mm |
| Width | 6mm |
| Mount Type | Through Hole |
| Series | IE |
| Maximum Operating Temperature | 90°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1100000h |
| Number of outputs | 1 |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 26.4V dc |
| Minimum Input Voltage | 21.6V |
| Number of Pins | 8 |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 40mA |
| Isolation Voltage | 1kV dc |
Key Features
- Compact DIP package with 8 pins suitable for through-hole mounting.
- Operating temperature ranges from -40°C to 90°C for reliable performance.
- Efficiency up to 80% ensures energy-saving operation.
- High isolation of 1000V DC enhances safety and noise immunity.
- MTBF of 1,100,000 hours indicates high reliability.
- Industry standard size with 11.68mm length, 6mm width, and 10.15mm depth.
- Designed for industrial applications requiring isolated DC/DC power conversion.
- Manufactured in Taiwan, Province Of China under XP Power's IE series.
Product Description
XP Power IE2424S DC/DC Converter is a high-performance isolated converter designed for industrial and electronic applications. The device provides a stable 24V DC output at 40mA from input voltages ranging between 21.6V and 26.4V DC, delivering up to 1 watt of output power.
The converter features a through-hole DIP package measuring 11.68mm in length, 6mm in width, and 10.15mm in depth, with 8 pins for easy PCB mounting. It supports a wide operating temperature range from -40°C to 90°C, making it suitable for harsh and demanding environments.
This IE series DC/DC converter provides 1000V DC of isolation voltage, ensuring electrical safety and noise reduction between input and output circuits. With an efficiency of up to 80%, it offers energy-efficient power conversion, reducing heat generation and energy losses.
The high MTBF rating of 1,100,000 hours confirms its reliability and long service life, ideal for continuous industrial use. The product is RoHS compliant and manufactured in Taiwan, Province Of China, adhering to stringent quality standards.
Compact DIP 8-pin package for through-hole PCB mounting. Wide input voltage range from 21.6V to 26.4V DC. Output voltage of 24V DC at 40mA current. 1 watt maximum output power suitable for low power applications. Operating temperature from -40°C to 90°C for rugged environments.
1000V DC isolation voltage for enhanced electrical safety. Efficiency up to 80% for energy saving. MTBF of 1,100,000 hours for high reliability.
This DC/DC converter is ideal for industrial power supply systems, embedded electronics, telecommunications equipment, and other precision devices requiring isolated and stable DC power. Its compact size and high reliability make it suitable for use in industrial automation, control systems, and instrumentation.
View our wide range of DC/DC Converters and related power supplies at EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The IE2424S DC/DC converter provides a stable output voltage of 24V DC at a current of 40mA.
This model operates with input voltages ranging from 21.6V to 26.4V DC.
The maximum output power of the IE2424S is 1 watt.
The efficiency of this DC/DC converter is up to 80%.
The dimensions of the IE2424S are 11.68mm in length, 6mm in width, and 10.15mm in depth.
This model features a through-hole DIP package for easy PCB mounting.
The isolation voltage of this converter is 1000V DC, enhancing electrical safety and noise immunity.
The operating temperature range for the IE2424S is from -40°C to 90°C.
The MTBF for this model is rated at 1,100,000 hours, indicating high reliability.
This DC/DC converter has one output channel.
The IE2424S is manufactured in Taiwan, Province Of China.
This DC/DC converter is designed for industrial applications requiring isolated DC/DC power conversion, such as embedded electronics and telecommunications equipment.
