XP Power Isolated DC/DC Converter, 15V DC Output, 600 mA, 9V to 21.6V DC Input, 1W Through Hole SIP Package IA2415S
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power IA DC/DC Converter, 15V dc/ 600 mA, 9V In |
| Brand | XP Power |
| Efficiency | 78% |
| Length | 19.3mm |
| Model | IA2415S |
| Depth | 10.16mm |
| Width | 6.09mm |
| Mount Type | Through Hole |
| Series | IA |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1100000h |
| Number of outputs | 2 |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 9V |
| Minimum Input Voltage | 21.6V dc |
| Number of Pins | 7 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 600mA |
| Isolation Voltage | 1kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Provides isolated dual output power with 1W maximum output.
- Operates over a wide input voltage range of 9V to 21.6V DC.
- High efficiency up to 78% to reduce power losses.
- Through hole SIP package with 7 pins for secure PCB mounting.
- Wide operating temperature range from -40°C to +85°C.
- 1000 VDC isolation voltage for enhanced safety and noise reduction.
- Industry standard pinout compatible with many designs.
- Long mean time between failures (MTBF) of 1,100,000 hours for dependable operation.
Product Description
XP Power IA2415S DC/DC Converter is a precision engineered isolated power supply module capable of providing 15V output at 600 mA with a maximum output power of 1W. Designed for use in a variety of industrial and electronic applications, this converter accepts input voltages ranging from 9V to 21.6V DC and integrates seamlessly into through hole SIP packages on printed circuit boards.
The IA2415S series features a robust 1000 VDC isolation rating, ensuring safe operation in noisy environments and protecting sensitive circuitry from voltage spikes. Its 7-pin configuration corresponds to an industry standard pinout, facilitating design compatibility with existing systems. The converter is engineered to operate reliably over an extended temperature range from -40°C to +85°C, suitable for demanding industrial, manufacturing, telecommunications, and laboratory environments.
This unit achieves an efficiency of approximately 78%, minimizing energy loss and heat generation during operation. Its compact design with a length of 19.3 mm, width of 6.09 mm, and depth of 10.16 mm allows for effective space utilization on crowded PCBs.
The IA2415S boasts a long operational life with a mean time between failures (MTBF) of 1.1 million hours, highlighting its quality and reliability for continuous duty applications. This converter is ideal for isolated power supply needs in industrial control, instrumentation, and embedded systems.
XP Power’s IA series continues to deliver trusted performance for power conversion requirements with its combination of isolation, efficiency, and ruggedness. Provides isolated dual output power with 1W maximum output. Operates over a wide input voltage range of 9V to 21.6V DC.
High efficiency up to 78% to reduce power losses. Through hole SIP package with 7 pins for secure PCB mounting. Wide operating temperature range from -40°C to +85°C. 1000 VDC isolation voltage for enhanced safety and noise reduction.
Industry standard pinout compatible with many designs. Long mean time between failures (MTBF) of 1,100,000 hours for dependable operation. Compact dimensions: length 19.3mm, width 6.09mm, depth 10.16mm. Manufactured in Taiwan, Province Of China.
Explore the full range of XP Power DC/DC Converters and similar power supply components on EnvMart for reliable industrial, telecommunications, laboratory, and manufacturing applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an output voltage of 15V DC with a maximum output current of 600 mA.
It operates over a wide input voltage range from 9V to 21.6V DC.
The maximum output power of this unit is 1W.
This converter achieves an efficiency of up to 78%, minimizing power losses during operation.
It features a robust isolation voltage of 1000 VDC, enhancing safety and noise reduction.
The dimensions of this model are 19.3 mm in length, 6.09 mm in width, and 10.16 mm in depth.
It operates reliably over a wide temperature range from -40°C to +85°C.
The SIP package of this model has 7 pins, following an industry standard pinout.
The IA2415S has a long mean time between failures (MTBF) of 1,100,000 hours.
It uses a through hole mounting type, suitable for secure PCB installation.
This model is manufactured in Taiwan.
It is suitable for a variety of industrial and electronic applications, including telecommunications and laboratory environments.
