HARWIN M52 Series Straight Surface PCB Socket 5-Contact 1 Row 1.27 mm Pitch Solder M52-5050545

HARWIN M52-5050545 is a straight surface PCB socket designed to provide secure and reliable electrical connections in various electronic applications. This PCB socket features 5 contacts configured in a single row with a precise 1.27 mm pitch, making it suitable for dense board designs.

The connector system supports board-to-board connections with a surface mount installation that enables efficient soldering. The housing is made from robust nylon material, offering excellent electrical insulation and mechanical strength.

Contacts are female, crafted from bronze and plated in gold to ensure optimal conductivity and resistance to oxidation or corrosion under operating conditions.

With a current rating of 12 A and a voltage rating of 500 V, this socket is capable of handling moderate power requirements. It operates effectively within a wide temperature range from -40°C to 105°C, thereby supporting diverse industrial and commercial environments.

This connector series, the M52 Series from HARWIN, is a reliable choice for applications in industrial equipment, telecommunications, and computer hardware where dependable board-to-board connections are critical.

Features a straight orientation suitable for board-to-board connections. Constructed with a nylon housing to ensure durability and insulation. Supports a current rating of 12 A and voltage rating of 500 V. Contacts are female, made of bronze with gold plating for enhanced conductivity and corrosion resistance.

Operates reliably in temperatures from -40°C to 105°C. Mounting type is surface mount ensuring easy soldering to PCBs. Provides a compact 1.27 mm pitch for high-density applications.

Ideal for industrial, telecommunications, and electronics manufacturing use cases, the HARWIN M52-5050545 PCB socket ensures reliable, high-quality performance. Explore more PCB Sockets and connectors on EnvMart for your project needs.
