LEM DK-B10 Series Current Transformer 200 A 20V dc, 50 V dc 21.7mm Bore DK 200 B10

LEM DK 200 B10 current transformer is a precision device developed for the measurement of DC currents up to 200 A. It features a large aperture with a 21.7 mm bore diameter suitable for accommodating conductor sizes typically used in industrial and electrical applications. The device operates with a supply voltage of 20 V or 50 V DC, providing versatility for varying installation requirements.

This current transformer is built with a screw terminal type ensuring secure and reliable electrical connections during panel mounting. Its compact physical size of 57.2 mm height, 30 mm width, and 89.7 mm depth allows easy integration into control panels and electrical enclosures where space optimization is critical.

Performance and safety are core strengths of this transformer, offering an accuracy of ±1% which guarantees precise current measurement crucial for process control and monitoring systems. The unit operates effectively within a temperature range of -20°C to +50°C, making it suitable for a variety of environments including industrial automation, electrical systems monitoring, and process control instrumentation.

Lightweight at 120 grams, the transformer also complies with the IEC 61010-1 safety standard, ensuring user safety and system reliability. Manufactured in the United States, the DK-B10 series stands out for its quality and durability in demanding electrical measurement applications.

Designed for measurement of DC currents with large aperture. Equipped with screw terminal type for secure connections. Panel mount type suitable for easy installation. Operates efficiently within -20 to 50°C operating temperature range.

Accuracy of ±1% ensures reliable current sensing. Compact dimensions of 57.2 x 30 x 89.7 mm optimize space utilization. Lightweight design with 120 g gross weight for easy handling and mounting. Meets IEC 61010-1 safety standard for electrical equipment.

Manufactured in the United States adhering to high-quality standards.

This current transformer is ideal for applications in industrial automation, electrical monitoring systems, process control, and electrical panel integration. Its design provides no insertion losses and simplifies maintenance with easy panel mounting.
