Phoenix Contact PCB Terminal Block SPT-SMD 1.5/4-V-5.0 R44 Series 4-Contact 5 mm Pitch Surface Mount Germany 1824323

Phoenix Contact 1824323 PCB Terminal Block from the SPT-SMD 1.5/4-V-5.0 R44 series is a highly reliable, surface-mounted terminal block designed for secure electrical connection on printed circuit boards. It features 4 contacts with a 5 mm pitch arranged in a single row, making it suitable for compact and precise electronic assembly applications.

This terminal block supports a current rating of up to 13.5 A and can withstand voltages up to 500 V, providing robust electrical performance for industrial and commercial electronics. The liquid crystal polymer housing ensures excellent mechanical strength and thermal stability, making it ideal for demanding environments.

The spring actuation lever and push-in spring technology ensure quick, secure, and tool-free connection and disconnection of conductors. It can accommodate both solid and stranded wire types ranging from 0.2 mm² to 1.5 mm² (24 AWG to 16 AWG), enhancing versatility.

Its surface mount design and packaging in tape-on-reel format comply with IEC 60283-3 standards, allowing smooth integration into automated assembly lines and reflow soldering processes. The straight orientation and twin soldering pins further assist in precise PCB alignment and secure mounting.

Handles currents up to 13.5 A ensuring robust performance. Supports voltages up to 500 V suitable for demanding circuits. Spring actuation lever enables easy and tool-free conductor connection and disconnection. Constructed with liquid crystal polymer housing for durability and stability.

Compatible with solid and stranded conductors from 0.2 mm² to 1.5 mm². Surface mount type allows integration into automated PCB assembly processes. Designed as a single row with straight orientation for efficient PCB layout.

Black color housing for standard industrial aesthetics. Dimensions: length 19 mm, width 7.7 mm, depth 13.6 mm to fit compact electronic designs.

This Phoenix Contact terminal block is commonly used in electronics manufacturing, industrial control systems, automation equipment, and other applications requiring safe and efficient PCB connections.

Its quality and reliability make it suitable for demanding industrial and laboratory environments where electrical safety and durability are paramount. Explore the extensive range of PCB Terminal Blocks and connectors available on EnvMart for all your electronic component needs.
