Phoenix Contact SPT-SMD 1.5/ 3-V-5.0 R32 Series PCB Terminal Block, 3-Contact, 5 mm Pitch, Surface Mount, 1 Row 1824310

Phoenix Contact 1824310 PCB Terminal Block is a high-quality electronic component designed for PCB assembly featuring 3 contacts and a 5 mm pitch suitable for surface mounting. This single row terminal block caters to currents up to 13.5 A and voltages up to 500 V, making it suitable for a broad range of industrial and commercial electronics applications.

The connector housing is made from liquid crystal polymer, providing excellent durability and electrical insulation. It utilizes advanced push-in spring connection technology, allowing for quick and secure wiring without additional tooling, compatible with wire sizes ranging from 0.2 mm² to 1.5 mm² or AWG 24 to 16. The straight orientation and black color enhance its versatility and integration with standard PCB designs.

Dimensionally, this terminal block measures 14 mm in length, 7.7 mm in width, and 13.6 mm in depth, offering compactness for efficient PCB space management. The series 1824310 is delivered in tape-on-reel packaging facilitating easy automated assembly processes. The product is manufactured in Germany and reflects Phoenix Contact's high standards for quality and reliability.

Supports currents up to 13.5 A for robust electrical performance. Accommodates wire sizes from 0.2 mm² to 1.5 mm² with spring connection technology. Constructed with durable liquid crystal polymer housing material ensuring longevity.

Designed for straightforward surface mounting with a single row configuration. Features a black color and straight orientation for standard PCB layouts. Operates safely up to 500 V voltage rating compatible with various industrial applications.

The terminal block has compact dimensions: 14 mm length, 7.7 mm width, and 13.6 mm depth. Complies with standard tape-on-reel packaging enabling automated PCB assembly.

This technical component is widely used in industrial electronics manufacturing, control systems, and other applications requiring reliable PCB terminal connections. Phoenix Contact's SPT-SMD series enhances productivity through efficient electrical connections and compatibility with automated assembly methods.
