STMicroelectronics 2-Channel Differential Line Transceiver, CMOS/TTL Logic, 16-Pin TSSOP, 3-5.5 V Supply ST3232CTR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.2mm |
| Length | 5.1mm |
| Model | ST3232CTR |
| Width | 4.5mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | ST3232C |
| Input Type | Single Ended |
| Maximum Operating Temperature | 70°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | 0°C |
| IC Type | Line Transceiver IC |
| Number Of Channels | 2 |
| Pin Count | 16 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS/TTL |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 3V |
| Maximum High Level Output Current | -1mA |
| Maximum Propagation Delay Time @ CL | 200ns |
| Supply Current | 2mA |
| Maximum Low Level Output Current | 1.6mA |
Key Features
- Operates with a supply voltage range from 3 V to 5.5 V.
- Contains two differential channels to transmit and receive signals.
- Surface mount device in a compact 16-pin TSSOP package.
- Maximum propagation delay time of 200 ns ensures fast data transmission.
- Operating temperature ranges from 0°C to 70°C for reliable performance.
- Low supply current consumption of about 2 mA.
- Designed with CMOS/TTL logic compatibility for versatile applications.
- Maximum high-level output current of -1 mA and low-level output current of 1.6 mA.
Product Description
STMicroelectronics ST3232CTR is a 2-channel differential line transceiver featuring CMOS/TTL logic family, housed in a 16-pin TSSOP surface mount package. It is specifically designed for RS-232 line drivers and receivers delivering reliable serial communication performance for industrial and commercial electronic systems.
The transceiver operates with a supply voltage between 3 V and 5.5 V and supports single-ended input and differential output signals. With a maximum propagation delay time of 200 ns at typical capacitive loading, it enables efficient high-speed data transmission with minimal signal distortion.
This device incorporates two independent channels enabling simultaneous transmit and receive operations. It maintains low supply current consumption of approximately 2 mA and supports high and low output current ratings of -1 mA and 1.6 mA respectively, making it suitable for a variety of RS-232 communication applications requiring power efficiency.
The compact 16-pin TSSOP package offers space-saving benefits with dimensions of length 5.1 mm, width 4.5 mm, and height 1.2 mm. The device is rated for an operating temperature range from 0°C to 70°C ensuring stable operation in industrial and laboratory environments.
Applications include line interface circuitry for industrial control, instrumentation, communications, and embedded systems requiring robust and efficient serial data transfer. The ST3232CTR is compliant with standard semiconductor manufacturing processes but does not carry specific automotive or industrial certifications.
Operates at 3 to 5.5 V supply voltage for flexible design integration. Two differential channels support robust serial communication. Compact 16-pin TSSOP surface mount packaging. Low power consumption of 2 mA typical supply current.
Fast signal processing with 200 ns maximum propagation delay. Designed for CMOS/TTL logic interfaces. Wide operating temperature range of 0°C to 70°C. Supports RS-232 line driver and receiver functions.
Explore the Electronics & Electricals category on EnvMart for a broad selection of semiconductor Line Interface ICs including counterparts and compatible modules for varying industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 3 V to 5.5 V.
It features two independent channels for transmitting and receiving signals.
The maximum propagation delay time is 200 ns, ensuring fast data transmission.
It is designed with CMOS/TTL logic compatibility, making it versatile for various applications.
The dimensions of this model are 5.1 mm in length, 4.5 mm in width, and 1.2 mm in height.
It operates within a temperature range of 0°C to 70°C, suitable for industrial and laboratory environments.
The supply current consumption is approximately 2 mA, which supports power efficiency in applications.
This model supports differential output signals, which are essential for RS-232 communication.
The maximum high-level output current is -1 mA.
It supports single-ended input signals, allowing for flexible integration in various systems.
This line transceiver is suitable for applications in industrial control, instrumentation, communications, and embedded systems requiring reliable serial data transfer.
It is housed in a compact 16-pin TSSOP surface mount package, which saves space in electronic designs.
