Vishay Thyristor SCR TO-48 Package 400 V 22 A 60 mA 420 A 1.7 V VS-22RIA40

The Vishay VS-22RIA40 is a high-quality thyristor SCR designed for industrial applications such as battery chargers, welders, plating equipment, regulated power supplies, and temperature or speed control circuits. Encapsulated in a TO-48 package with a screw mount, this device offers excellent mechanical stability and electrical isolation.

Rated for an average on-state current of 22 A and surge current rating up to 420 A, it supports demanding power switching tasks. The repetitive peak reverse voltage of 400 V and repetitive peak off-state current of 10 mA make it suitable for high-voltage applications. The maximum gate trigger current of 60 mA and maximum gate trigger voltage of 2 V ensure precise and reliable triggering, while the maximum on-state voltage of 1.7 V helps to reduce power losses.

The device withstands a wide operating temperature range from -65°C to 125°C, making it robust for harsh industrial environments. With only 2 pins and screw mounting type, installation and replacement are straightforward. This thyristor does not comply with automotive standards and does not have specific certification approvals.

Designed for phase control and bistable switching applications. Supports high surge currents up to 420 A. Wide operating temperature range from -65°C to 125°C. Low on-state voltage reduces power loss during conduction. Reliable gate triggering with low gate current and voltage requirements.

Encapsulated TO-48 screw-mount package provides mechanical and electrical stability. Suitable for industrial control applications including welders and battery chargers.
