Schneider Electric LC2K Reversing Contactor, 24V AC Coil, 3-Pole, 6 A, 3 kW, 3 NO, 690V AC LC2K0601B7

Schneider Electric LC2K0601B7 is a high-quality Reversing Contactor designed for motor control applications, operating on a 24V AC coil. This compact electromechanical device is specialized for switching and reversing three-phase motor supplies, ideal for industrial control systems.

Equipped with 3 poles configured as 3 normally open contacts and an auxiliary contact configured as 1 normally closed, it ensures reliable motor direction reversal and status feedback. With a contact voltage rating of 690V AC and operational current of 6 A, this contactor is suited for medium motor loads up to 3 kW power rating.

The unit supports AC utilization categories including AC-3 and AC-4, making it efficient for motor control and resistive loads. It includes a screw clamp terminal type that securely handles conductors up to 4 mm² cross-section, facilitating installation and maintenance.

Typical applications include reversing direction of three-phase motors in conveyors, motor starters in compact control panels, and machinery requiring frequent start-stop and directional changes, such as gearboxes and winches.

Schneider Electric LC2K0601B7 is rated for ambient temperatures from -25 to 50 °C and features IP20 protection along with flame-retardant insulating materials. Mounting options include plate and rail to integrate seamlessly into industrial panels.

Designed for reversing three-phase motor supplies. 3 NO power poles and 1 NC auxiliary contact provide robust switching and control. Rated for 690V AC contact voltage and 6A operational current. Screw clamp terminals support up to 4 mm² conductors.

Supports AC utilisation categories AC-3 and AC-4 for motor and resistive loads. Plate and rail mounting for flexible installation. Operational temperature range -25°C to 50°C for diverse environments. Compact dimensions: 58 mm length, 90 mm width, 57 mm depth.

Complies with CCC, CSA, EAC, IEC, RoHS, and UL standards ensuring safety and quality. Suitable for industrial automation, motor control centers, manufacturing machinery, and HVAC systems.

This product is part of Schneider Electric's LC2K series, offering durable, reliable performance for motor control and reversing applications. Its Better World Claim includes design for disassembly, supporting sustainability goals.
