Schneider Electric TeSys K 3 Pole Reversing Contactor 230V AC Coil, 9A, 4kW LC2K0901P7

Free Delivery in India | Lowest Global Shipping Charges

Schneider Electric TeSys K 3 Pole Reversing Contactor 230V AC Coil, 9A, 4kW LC2K0901P7

Name: Schneider Electric TeSys K 3 Pole Reversing Contactor 230V AC Coil, 9A, 4kW LC2K0901P7
Brand: Schneider Electric
SKU: 198152
Price: 131.46 USD
Availability: InStock



Category Reversing Contactor Brand Schneider Electric Condition New

Specifications

Country of Origin	France
Brand	Schneider Electric
Function	Motor Control, Resistive Load, Reversing
Length	58mm
Model	LC2K0901P7
Depth	57mm
Width	90mm
Mount Type	DIN Rail
Series	LC2K
Power Rating	4kW
Maximum Operating Temperature	50°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	CCC, CSA, EAC, IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	230V ac
Normal State Configuration	3 NO
Better World Claim	Designed for Disassembly
Contact Current	9A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NC
Operational Current Ie	9A
Control Circuit Voltage Uc	230V ac
Contactor Application	Motor Control, Resistive Load
Pole and Throw Configuration	3
Ue Rated Voltage Power circuit	690 V AC 50/60 Hz, Signalling circuit

Key Features

Features a 3-pole configuration suitable for reversing applications.
Designed for a contact voltage of 690V AC and contact current rating of 9A.
Power rating of 4 kW at 230V AC ensures efficient operation.
Includes 1 auxiliary contact with a 1 NC configuration for additional circuit control.
Mountable via DIN Rail for easy installation.
Controlled by a 230V AC coil voltage circuit.
Operates safely within -25°C to 50°C temperature range.
Constructed in France adhering to standards CCC, CSA, EAC, IEC, RoHS, and UL.

Product Description

Schneider Electric LC2K0901P7 TeSys K series 3 Pole Reversing Contactor is engineered for precise motor control and resistive load management. It operates using a 230V AC coil and supports a contact voltage of up to 690V AC with a contact current rating of 9A, making it suitable for various industrial, electrical, and automation applications.

This reversing contactor features 3 normally open (NO) poles and is accompanied by a single auxiliary contact with a normally closed (NC) configuration, enhancing its functionality in motor control circuits. The DIN rail mounting facilitates straightforward and secure installation within control panels.

The device is robustly designed to operate in ambient temperatures ranging from -25°C to 50°C, ensuring reliability in challenging environments. Its compact form factor measures 58mm in length, 90mm in width, and 57mm in depth, allowing flexibility in space-constrained setups.

Compliant with international standards including CCC, CSA, EAC, IEC, RoHS, and UL, this contactor also embodies Schneider Electric's Better World initiative with claims of designed for disassembly, promoting sustainability and environmental responsibility.

Features a 3-pole reversing configuration suitable for motor control and resistive loads. Operates at 230V AC coil voltage with a 9A contact current rating. Rated for power handling up to 4 kW at 230V AC. Equipped with one auxiliary contact configured as 1 NC for enhanced control.

Mountable on DIN rail for ease of integration in control systems. Supports a broad operating temperature from -25°C to 50°C.

This product is ideal for industrial automation, motor control panels, HVAC systems, and other manufacturing and electrical applications requiring reliable reversing contactors. The French manufacturing origin ensures high-quality build standards for demanding operational environments.

Explore Schneider Electric Reversing Contactors and other electrical automation components on EnvMart for superior quality and performance.
