Schneider Electric TeSys K 3-Pole Reversing Contactor, 48V AC Coil, 6A, 3 kW, 690V AC LC2K0610E7
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LC2K0610E7 |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | TeSys K |
| Power Rating | 3kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | RoHS, UL, CCC, CSA, EAC, IEC |
| Contact Voltage | 690V ac |
| Coil Voltage | 48V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 6A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NO |
| Operational Current Ie | 6A |
| Control Circuit Voltage Uc | 48V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| Ue Rated Voltage Power circuit | 690 V AC 50/60 Hz, Signalling circuit |
Key Features
- Compact 3-pole design suitable for motor control applications.
- DIN rail mountable for efficient panel integration.
- Includes 1 normally open auxiliary contact for signaling.
- Equipped with screw clamp terminals for secure connections.
- Designed for operation in temperatures ranging from -25°C to 50°C.
- Mechanical interlock and pre-wired reversing circuit for enhanced safety and ease of use.
- Complies with IEC, UL, CSA, CCC, EAC standards ensuring global compatibility.
- Supports 50/60Hz operation compatible coil voltage.
Product Description
Schneider Electric LC2K0610E7 is a compact 3-pole TeSys K reversing contactor designed for motor control and resistive load applications with a rated power of 3 kW and operational voltage up to 690V AC. It features a 48V AC coil compatible with both 50Hz and 60Hz frequencies.
This contactor is DIN rail mountable, providing easy installation and integration into control panels. Equipped with screw clamp terminals, it ensures reliable wiring and connection security. The device includes one normally open auxiliary contact for signaling and control purposes.
Its mechanical interlock and pre-wired reversing circuit enhance operational safety and simplify wiring for reversing motor applications. The operating temperature range of -25°C to 50°C allows versatile use in various industrial environments.
LC2K0610E7 meets multiple international standards including IEC, UL, CSA, CCC, and EAC, making it suitable for global applications. It is also compliant with RoHS and carries a Green Premium certification, emphasizing its environmentally friendly design.
Compact dimensions measure 90 mm width, 58 mm length, and 57 mm depth, making it ideal for space-constrained installations. The contactor is suitable for industrial, manufacturing, HVAC, and motor control applications requiring reliable reversing contactor functions.
Compact 3-pole design suitable for motor control applications. DIN rail mountable for efficient panel integration. Includes 1 normally open auxiliary contact for signaling. Equipped with screw clamp terminals for secure connections.
Designed for operation in temperatures ranging from -25°C to 50°C. Mechanical interlock and pre-wired reversing circuit for enhanced safety and ease of use. Complies with IEC, UL, CSA, CCC, EAC standards ensuring global compatibility.
Dimensions are 90mm width, 58mm length, and 57mm depth. Supports 50/60Hz operation compatible coil voltage. Certifications include RoHS and Green Premium compliance.
This Schneider Electric TeSys K Reversing Contactor LC2K0610E7 is a premium choice for reliable motor reversing control in industrial settings. Explore the full range of contactors and related control gear products at EnvMart for your electrical automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Schneider Electric TeSys K reversing contactor has a power rating of 3 kW.
This model can operate at a maximum voltage of 690V AC.
The coil voltage for this reversing contactor is 48V AC.
The dimensions of this contactor are 90 mm in width, 58 mm in length, and 57 mm in depth.
This reversing contactor features a 3-pole design.
It is equipped with screw clamp terminals for secure connections.
The operating temperature range for this model is from -25°C to 50°C.
Yes, it includes one normally open auxiliary contact for signaling and control purposes.
This model complies with IEC, UL, CSA, CCC, and EAC standards, ensuring global compatibility.
The rated current for this reversing contactor is 6A.
Yes, it is designed for DIN rail mounting, allowing for efficient panel integration.
It is designed for motor control and resistive load applications.
