APEM Toggle Switch, PCB Mount, On-Off-On DPDT, Through Hole Terminal, 20 V dc, 20 V ac TL49W0050

The APEM TL49W0050 toggle switch is a precise and durable On-Off-On configuration switch intended for PCB mounting in low level switching applications. Operating at 20 V dc and 20 V ac with a contact current of 400 mA, it is suitable for industrial and electronic equipment requiring reliable circuit control.

This DPDT switch features through hole terminals and a robust brass actuator with a length of 5.3 mm, providing stable operation across a temperature range from -30°C to 85°C. The compact dimensions (19.58 mm height, 9.6 mm length, and 8.1 mm width) allow easy installation in space-constrained assemblies.

Designed to endure up to 60,000 operations in two-position and 30,000 in three-position switch modes, the product's gold-plated brass terminals and PBT case ensure excellent conductivity and durability. Additionally, it is totally sealed, enabling immersion cleaning and wave soldering processes that can withstand temperatures up to 260°C for 5 seconds.

This switch complies with RoHS standards and is manufactured in France, reflecting quality and environmental compliance. The minimum load current supports sensitive electronic circuits, down to 10 μA at 5 V dc, making it ideal for precision applications in industrial, electronic manufacturing, automation, and instrumentation.

This switch features a double pole double throw (DPDT) contact configuration for versatile circuit control. It employs through hole terminals suitable for secure PCB mounting. The switch has a brass actuator with a length of 5.3 mm ensuring durability.

Operating temperature range is from -30°C to a maximum of 85°C, suitable for varying environments. The unit supports a contact current of 400 mA and voltage rating of 20 V for both DC and AC. It offers a switch configuration of On-Off-On with long service life up to 60,000 operations in two-position and 30,000 in three-position modes.

The compact dimensions measure 19.58 mm height, 9.6 mm length, and 8.1 mm width allowing integration into tight spaces. This product complies with RoHS standards, assuring environmentally friendly manufacturing. Constructed with a PBT case and gold-plated brass terminals for reliable electrical performance.

Designed for low level switching applications, it is washable and wave solderable withstanding 260°C for 5 seconds.

This product is suitable for use in Electronics & Electricals, Industrial Automation Systems, Instrumentation, and Manufacturing applications where reliable and precise switching is required. Explore more Toggle Switches and other control switches on EnvMart for your industrial and laboratory needs.
