TDK 1 nF Multilayer Ceramic Capacitor 50V dc ±10% Tolerance Surface Mount 0402 Package C1005X7R1H102K050BA

TDK C1005X7R1H102K050BA is a 1 nF multilayer ceramic capacitor designed for surface mount technology (SMT) with a 50V dc voltage rating and ±10% capacitance tolerance. This 0402 package component features a stacked construction with multilayer dielectrics and inner electrodes that alternate to ensure superior mechanical strength and reliability.

The X7R dielectric allows the capacitor to operate effectively across a wide temperature range from -55°C to 125°C, making it suitable for various industrial, commercial, and consumer electronic applications. Surface mount solder termination facilitates automated placement and soldering processes, and the tape & reel packaging supports high-volume assembly.

This capacitor offers low equivalent series resistance (ESR) and low equivalent series inductance (ESL), which contribute to outstanding frequency characteristics and minimal self-heating, providing high resistance to ripple current. Its non-polarized nature allows flexible use in both AC and DC circuits.

Common use cases include power supply decoupling, filtering, noise suppression in mobile devices, telecommunications equipment, audio-video electronics, home appliances, personal computers, and industrial robots under normal operating conditions.

Capacitance value of 1 nF with ±10% tolerance. 40V dc rated voltage with stable X7R dielectric. Compact 0402 package: length 1mm, width 0.5mm, height 0.5mm. Temperature range from -55°C to 125°C. RoHS and REACH compliant.

Stacked multilayer construction for mechanical strength. Surface mount solder termination type. Tape & reel packaging designed for automated insertion. Low ESR and high ripple current capacity ensure reliable performance.

Non-polar capacitor for versatile electronic uses. Explore the Electronics & Electricals category for more Multilayer Ceramic Capacitors and related passive components on EnvMart.
