TDK 10 nF Multilayer Ceramic Capacitor 25V DC ±10% Tolerance Surface Mount 0402 Case C1005X7R1E103K050BB

Free Delivery in India | Lowest Global Shipping Charges

TDK 10 nF Multilayer Ceramic Capacitor 25V DC ±10% Tolerance Surface Mount 0402 Case C1005X7R1E103K050BB



Category Multilayer Ceramic Capacitors Brand TDK Condition New

Specifications

Country of Origin	India
Voltage	25V dc
Brand	TDK
Height	0.5mm
Length	1mm
Model	C1005X7R1E103K050BB
Packaging	Tape & Reel
Width	0.5mm
Mount Type	Surface
Construction	Stacked
Termination Type	Solder
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	10nF
Minimum Operating Temperature	-55°C
Standards/Approvals	REACH, RoHS
Package/Case	0402
Dielectric	X7R

Key Features

The capacitor uses X7R dielectric providing stable performance.
Operates reliably from -55°C up to 125°C.
Construction features stacked multilayer ceramic dielectrics and electrodes.
Termination type is solder compatible with standard PCB assembly.
Packaged in tape and reel format for automated insertion.
Component is RoHS and REACH compliant ensuring environmental safety.

Product Description

TDK C1005X7R1E103K050BB is a high-reliability 10 nF multilayer ceramic capacitor designed for surface mount applications, offering 25V DC voltage rating with ±10% capacitance tolerance. This capacitor belongs to the commercial grade C series by TDK, featuring a stacked monolithic structure of multilayer ceramic dielectrics and electrodes. The construction assures superior mechanical strength and excellent frequency characteristics, including low equivalent series resistance (ESR) and inductance (ESL).

The X7R dielectric material provides stable capacitance over a broad temperature range from -55°C to 125°C, making it suitable for diverse industrial, electronic, and power supply circuits. Its compact 0402 package measuring 1mm by 0.5mm with a height of 0.5mm allows for space-saving PCB designs in mobile devices, telecommunications, AV equipment, home appliances, computers, and industrial robots.

Termination is a solder type, compatible with automated surface mounting techniques. The product is supplied in tape and reel packaging to enhance production efficiency by enabling seamless insertion into machinery. The capacitor complies with RoHS and REACH standards ensuring it meets current environmental and safety regulations.

This model is particularly suited for applications requiring low self-heating and resistance to ripple currents due to its low ESR characteristics, with no polarity considerations simplifying circuit design and assembly.

The capacitor offers outstanding frequency characteristics enhancing circuit performance. Low ESR and ESL contribute to minimal signal losses and heat generation. High mechanical strength due to monolithic design supports reliable operation.

Environmental compliance with RoHS and REACH supports green manufacturing. Compact 0402 package size suits miniaturized electronics assemblies. Wide temperature range enables use in various industrial conditions. Tape and reel packaging optimizes automated manufacturing processes.
