Broadcom ACNT-H87A-500E Optocoupler Surface Mount 8-Pin Voltage Sensor ACNT-H87A-500E

Broadcom ACNT-H87A-500E optocoupler is a surface mount optical isolation amplifier specifically designed for voltage sensing in electronic power converter applications such as motor drives and renewable energy systems. It features an 8-pin configuration housed in a compact 15 mm Stretched SO-8 package, suitable for precise and reliable voltage measurement tasks.

Its high input impedance of 1 GΩ and 0 to 2 V nominal input range make it ideal for interfacing with resistive voltage dividers used in DC-link voltage scaling. The device employs advanced sigma-delta (Σ - Δ) modulation technology to provide a differential output voltage proportional to the input voltage with high accuracy and stability.

The ACNT-H87A-500E supports a maximum input current of 230 mA, operates reliably within a temperature range of -40°C to 125°C, and supports an output supply voltage ranging from 3 V to 55 V. Additional features include low gain drift of -35 ppm/°C, offset voltage drift of 21 μV/°C, and a maximum non-linearity of 0.1% enabling precise voltage sensing performance across varying conditions.

This optocoupler provides an active-high shutdown pin, a bandwidth of 100 kHz, and excellent common-mode transient immunity of 15 kV/μs, ensuring robustness in electrically noisy environments commonly encountered in industrial and renewable energy systems. Its surface mount design allows for easy integration in automated assembly lines.

Features a high input impedance of 1 GΩ ideal for isolated voltage sensing. Operates over a wide temperature range from -40°C to 125°C. Supports a maximum input current of 230 mA for robust performance. Provides a nominal input range of 0 to 2 V with excellent linearity.

Incorporates advanced sigma-delta modulation technology for accurate output. Offers a wide supply voltage range of 3 V to 55 V on the output side. Equipped with a compact 15 mm Stretched SO-8 package suitable for automated insertion.

Ensures high common-mode transient immunity of 15 kV/μs enhancing noise resistance.

This product is designed for use in industrial, renewable energy, and motor drive applications where precise and isolated voltage sensing is critical. Its compact footprint and robust electrical performance make it suitable for modern power electronics systems and electronics manufacturing.
