Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 22 μH ±20% 2.9 A Idc ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4.5mm |
| Length | 6.5mm |
| Model | ETQP4M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 2.9A |
| Pin Count | 2 |
| Maximum DC Resistance | 138.6mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a metal composite core for high heat resistance and reliability.
- Designed for surface mount with tape and reel packaging for easy PCB assembly.
- Supports high operating temperature up to 150°C ensuring stable operation.
- Rated to meet automotive standard AEC-Q200 for robustness in automotive applications.
- Features shielding to reduce noise and interference in circuits.
- Low DC resistance of 138.6mΩ enhances efficiency in power circuits.
- Moulded wirewound construction for vibration resistance and durability.
- Ideal for noise filtering in various drive circuitry requiring high temperature and peak current handling.
Product Description
Panasonic ETQP4M is a shielded wirewound Surface Mount Inductor featuring a robust metal composite core. This design provides high heat resistance and high reliability, making it suitable for industrial, automotive, and electronics manufacturing applications. It offers an inductance of 22 μH with ±20% tolerance and supports a maximum DC current of 2.9 A, enabling stable and efficient electrical performance.
The inductor’s compact surface mount package and tape & reel packaging facilitate efficient assembly on printed circuit boards. It complies with the automotive standard AEC-Q200, ensuring durability and high vibration resistance required in harsh automotive environments.
Its operating temperature range extends up to 150°C, including self-heating, which supports its use in high temperature applications. The shielded construction minimizes electromagnetic interference, improving signal integrity and noise filtering in sensitive circuits.
Key physical dimensions include a length of 6.5mm, height of 4.5mm, and depth of 6mm. The low maximum DC resistance of 138.6 milliohms reduces power loss and improves energy efficiency.
This inductor is moulded with a wirewound construction, ensuring mechanical durability and stable inductance under vibration and thermal stress. The component is suitable for use in power supplies, noise filters, and automotive electronic systems requiring high temperature operation and peak current handling capability.
Constructed with metal composite core for heat resistance and reliability. Shielded wirewound design reduces noise and electromagnetic interference. Supports up to 2.9 A DC current at 22 μH inductance with ±20% tolerance.
Complies with AEC-Q200 automotive standard for high vibration resistance. Compact surface mount package dimensions: 6.5mm length, 4.5mm height, 6mm depth. Operating temperature range from -40°C to 150°C suits harsh environments.
Low DC resistance at 138.6mΩ enhances electrical efficiency. Packaged in tape and reel for automated PCB assembly.
Applications include noise filtering and power management circuits in industrial, automotive, and consumer electronics sectors. The Panasonic ETQP4M series offers reliability and stable performance for demanding electronic designs. Explore Panasonic inductors and similar surface mount components on EnvMart for advanced electronic manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 22 μH with a tolerance of ±20%.
It can handle a maximum DC current of 2.9 A.
The dimensions are 6.5 mm in length, 4.5 mm in height, and 6 mm in depth.
The maximum operating temperature is 150°C.
It features a wirewound construction with a metal composite core.
Yes, it complies with the automotive standard AEC-Q200.
The inductor is packaged in tape and reel format for easy PCB assembly.
The maximum DC resistance is 138.6 mΩ.
It is suitable for noise filtering and power management circuits in industrial, automotive, and consumer electronics sectors.
The minimum operating temperature is -40°C.
It uses a surface mount termination style.
It meets RoHS standards for environmental compliance.
