Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 2.2 μH ±20 % 14.8 A Idc ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4mm |
| Length | 10.7mm |
| Model | ETQP4M |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 14.8A |
| Pin Count | 2 |
| Maximum DC Resistance | 7.48mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a robust metal composite core providing high heat and vibration resistance.
- Designed for operation up to 155°C including self-heating effects.
- Low audible noise ideal for noise filtering in sensitive drive circuitry.
- Complies with AEC-Q200 automotive standard ensuring reliability in automotive applications.
- Packaged in tape and reel format for efficient high-volume automated assembly.
- Offers a maximum DC resistance of 7.48 mΩ minimizing power losses.
- Features shielded construction to reduce electromagnetic interference.
Product Description
Panasonic ETQP4M shielded wirewound Surface Mount Inductor with metal composite core delivers reliable performance for industrial and automotive electronic applications requiring high current and temperature tolerance.
With an inductance value of 2.2 μH ±20 %, this surface mount device supports a maximum DC current of 14.8 A, allowing it to handle peak current loads efficiently.
The inductor is designed with a metal composite core that enhances heat resistance and vibration durability, ensuring long-term stability and inductance accuracy across varying operating conditions.
Its compact size, including a length of 10.7 mm, height of 4 mm, and depth of 10 mm, makes it suitable for dense PCB designs where space saving is critical. The product meets the AEC-Q200 automotive qualification standard, highlighting its robustness in automotive and other harsh environment applications.
Shielded construction reduces electromagnetic interference, improving noise filtering for sensitive drive circuits. This design also ensures low audible noise operation, beneficial for noise-sensitive electronic devices.
High heat resistance metal composite core. Operation temperature up to 155°C including self heat. Low audible noise suitable for noise filters. Automotive AEC-Q200 qualified. Tape and reel packaging for automated assembly.
Compact dimensions with surface mount termination. Shielded construction for EMI reduction. Maximum DC current capacity of 14.8 A.
This Panasonic ETQP4M series inductor is ideal for industrial electronics, automotive systems, telecommunications equipment, and power management circuits where reliable inductance and current handling is critical.
Explore additional Panasonic power inductors and electronic components available on EnvMart for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 2.2 μH with a tolerance of ±20%.
It can handle a maximum DC current of 14.8 A.
The maximum operating temperature is 155°C, including self-heating effects.
This inductor features a metal composite core, which provides high heat and vibration resistance.
It is packaged in tape and reel format, which is suitable for efficient high-volume automated assembly.
The dimensions are 10.7 mm in length, 4 mm in height, and 10 mm in depth.
It complies with the AEC-Q200 automotive standard, ensuring reliability in automotive applications.
The maximum DC resistance is 7.48 mΩ, which helps minimize power losses.
This model has a wirewound construction and features shielded construction to reduce electromagnetic interference.
The minimum operating temperature is -55°C.
It is suitable for industrial electronics, automotive systems, telecommunications equipment, and power management circuits.
