Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core, 1 μH ±20% 10.7 A IDC ETQP3M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 6.5mm |
| Model | ETQP3M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP3M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 10.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 8.7mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- High heat resistance and reliability with metal composite core construction.
- Shielded design reduces electromagnetic interference.
- Wide operating temperature range from -40°C to 150°C.
- Low DC resistance of 8.7 mΩ ensures efficient performance.
- Complies with Automotive Standard AEC-Q200 for reliability.
- Compact package with 6.5 mm length, 3 mm height, and 6 mm depth.
- Surface mount termination for efficient board assembly.
- High vibration resistance due to integral construction.
Product Description
Panasonic ETQP3M shielded wirewound surface mount inductor utilizes a metal composite core that provides excellent heat resistance and operational reliability. Featuring a 1 μH inductance with ±20% tolerance and a maximum DC current capability of 10.7 A, this inductor supports demanding electronic and automotive applications.
The unit is constructed with wirewound technology on a ferrous alloy magnetic core, ensuring stable inductance characteristics and low audible noise. Its shielded construction minimizes electromagnetic interference, making it ideal for sensitive circuitry.
Designed for operation up to 150°C and withstanding self-generated heat, the inductor operates reliably across a wide temperature range from −40°C to 150°C. The compact surface mount package (6.5 mm length, 3 mm height, 6 mm depth) enhances PCB layout flexibility and assembly efficiency.
Compliance with the automotive standard AEC-Q200 ensures suitability for automotive environments requiring high vibration resistance and reliability. The inductor's low DC resistance of 8.7 mΩ contributes to efficient current flow and reduced power loss.
This inductor is especially suited as a noise filter for drive circuits requiring high temperature operation and peak current handling, including industrial electronics, automotive systems, power supplies, and telecommunications equipment.
High heat resistance and reliability with metal composite core construction. Shielded design reduces electromagnetic interference. Wide operating temperature range from -40°C to 150°C. Low DC resistance of 8.7 mΩ ensures efficient performance.
Complies with Automotive Standard AEC-Q200 for reliability. Compact package with 6.5 mm length, 3 mm height, and 6 mm depth. Surface mount termination for efficient board assembly. High vibration resistance due to integral construction.
Suitable for noise filtering in high temperature and peak current applications. Discover a broad range of industrial-grade Surface Mount Inductors suited for diverse electronics manufacturing and assembly requirements here at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 1 μH with a tolerance of ±20%.
It has a maximum DC current capability of 10.7 A.
The dimensions of this inductor are 6.5 mm in length, 3 mm in height, and 6 mm in depth.
This model operates reliably across a wide temperature range from -40°C to 150°C.
It utilizes a metal composite core, which provides excellent heat resistance and reliability.
The DC resistance is low at 8.7 mΩ, ensuring efficient performance.
Yes, it complies with the Automotive Standard AEC-Q200 for reliability.
The termination style is surface mount, which facilitates efficient board assembly.
It is packaged in tape and reel format for easy handling and assembly.
This inductor is constructed using wirewound technology on a ferrous alloy magnetic core.
This model is especially suited for noise filtering in high temperature and peak current applications, including automotive systems and power supplies.
In addition to AEC-Q200, it also complies with RoHS standards.
