Panasonic Shielded Wirewound Surface Mount Inductor Metal Composite Core 15 μH ±20% 3 A Idc ETQP3M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 6.4mm |
| Model | ETQP3M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP3M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 3A |
| Pin Count | 2 |
| Maximum DC Resistance | 109.12mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a metal composite core for high heat resistance and reliability.
- Features a shielded wirewound design for excellent inductance stability.
- Supports maximum operating temperature up to 155°C for demanding environments.
- Compliance with automotive standard AEC-Q200 ensures robust performance.
- Packaged in tape and reel format for efficient assembly and automation.
- Minimum operating temperature down to -55°C suits a wide range of applications.
- Low maximum DC resistance of 109.12 mΩ reduces power losses during operation.
- Compact package with dimensions 6.4 mm length, 3 mm height, and 6 mm depth.
Product Description
Panasonic ETQP3M shielded wirewound surface mount inductor with metal composite core provides 15 μH inductance with ±20% tolerance and supports a maximum DC current of 3 A. Designed to offer high heat resistance and reliability, it uses a metal composite core and features a shielded construction to minimize electromagnetic interference.
This surface mount inductor meets the automotive standard AEC-Q200, making it suitable for automotive and industrial applications where high reliability under harsh conditions is essential. It operates reliably from -55°C up to 155°C, including self-heating, ensuring stable performance across temperature extremes.
The wirewound construction offers excellent inductance stability with ferrous alloy magnetic materials, resulting in low audible noise and high vibration resistance. The component is moulded and has a maximum DC resistance of 109.12 mΩ, reducing power loss.
Compact in size, with dimensions of 6.4 mm length, 3 mm height, and 6 mm depth, this inductor is supplied in tape and reel packaging suited for automated PCB assembly. The surface mount termination style facilitates easy integration on circuit boards.
It is ideal for use in electronic circuits requiring noise filtering, power conversion, and other high-temperature, high-current applications in industrial, automotive, and commercial electronics.
Constructed with metal composite core for durability and heat resistance. Shielded wirewound design reduces electromagnetic interference. High operating temperature range from -55°C to 155°C. Complies with automotive standard AEC-Q200 for reliable automotive use.
Compact dimensions enable integration into high-density boards. Low DC resistance minimizes power loss and heats generation. Supplied in tape and reel packaging for automated production. Suitable for industrial, automotive, and commercial electronic applications.
Offers stable inductance performance under temperature and bias conditions. Ensures low audible noise for sensitive applications. Explore more Surface Mount Inductors at EnvMart for your electronic component requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an inductance of 15 μH with a tolerance of ±20%.
The maximum DC current supported by this inductor is 3 A.
It has dimensions of 6.4 mm in length, 6 mm in depth, and 3 mm in height.
It operates reliably in a temperature range from -55°C to 155°C.
Yes, it complies with the automotive standard AEC-Q200, ensuring robust performance in automotive applications.
The maximum DC resistance is 109.12 mΩ, which helps reduce power losses during operation.
It is constructed with a metal composite core, providing high heat resistance and reliability.
The inductor is packaged in a tape and reel format, which is suitable for automated assembly processes.
This unit features a surface mount termination style for easy integration onto circuit boards.
It utilizes a wirewound construction, which offers excellent inductance stability and low audible noise.
It meets RoHS standards, ensuring compliance with environmental regulations.
It is suitable for use in electronic circuits requiring noise filtering, power conversion, and high-temperature applications in automotive and industrial settings.
