Amphenol Communications Solutions Minitek Pwr Series Right Angle Through Hole PCB Header, 16 Contacts, 3 10160920-1240100LF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1000V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 9.5A |
| Model | 10160920-1240100LF |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer, Polyamide 66 |
| Contact Material | Copper Alloy |
| Series | Minitek Pwr |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 3mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Female |
| Shrouded/Unshrouded | Shrouded |
| Tail Pin Length | 2.41mm |
Key Features
- The PCB header uses a liquid crystal polymer and polyamide 66 housing for high durability.
- It is a shrouded, dual-row connector with right angle orientation.
- Contacts are made of high conductivity copper alloy plated with gold for superior performance.
- Tail pins are 2.41 mm long and use solder termination type.
- The product operates reliably from -40°C to 105°C temperature range.
- Connector complies with IEC 60695-2-12 and IEC 60695-2-13 standards for safety and quality.
- Suitable for use in industrial electronic assemblies requiring secure, high-current PCB connections.
Product Description
Amphenol Communications Solutions 10160920-1240100LF Minitek Pwr Series right angle through hole PCB header is engineered for reliable electrical connections in high performance industrial and electronic applications. Featuring 16 contacts arranged in two rows with a 3 mm pitch, this shrouded connector supports currents up to 9.5A at 1000 volts, ensuring robust data and power transmission.
The housing material combines liquid crystal polymer and polyamide 66 providing excellent mechanical strength and heat resistance. Its gold-plated copper alloy contacts guarantee high conductivity and corrosion resistance. The solder termination with a tail pin length of 2.41 mm facilitates secure PCB mounting.
Its operating temperature range from -40°C to 105°C makes it suitable for challenging environments. It complies with IEC 60695-2-12 and IEC 60695-2-13 standards, confirming its safety and quality for industrial use.
This connector is ideal for applications including industrial machinery control systems, power electronics, communication modules, and PCB assemblies where reliable, durable connector performance is critical.
The PCB header uses a liquid crystal polymer and polyamide 66 housing for high durability. It is a shrouded, dual-row connector with right angle orientation. Contacts are made of high conductivity copper alloy plated with gold for superior performance.
Tail pins are 2.41 mm long and use solder termination type. The product operates reliably from -40°C to 105°C temperature range. Connector complies with IEC 60695-2-12 and IEC 60695-2-13 standards for safety and quality.
Suitable for use in industrial electronic assemblies requiring secure, high-current PCB connections. Explore more products in the PCB Headers category on EnvMart for comprehensive electronic components suitable for industrial, laboratory, and manufacturing setups.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB header is 1000V.
This connector can support currents up to 9.5A.
The housing is made from liquid crystal polymer and polyamide 66, providing high durability.
This model features a 3mm pitch with 16 contacts arranged in two rows.
It operates reliably within a temperature range of -40°C to 105°C.
The PCB header uses a solder termination type.
The tail pins are 2.41 mm long.
This connector is shrouded, which enhances its reliability in connections.
It complies with IEC 60695-2-12 and IEC 60695-2-13 standards for safety and quality.
It is suitable for industrial machinery control systems, power electronics, communication modules, and PCB assemblies.
The contacts are made of high conductivity copper alloy plated with gold for superior performance.
This model has a right angle orientation, which is beneficial for space-constrained applications.
