Murata 26 MHz Crystal Unit Surface Mount 4-Pin 0.65 mm Height 1.6 mm Length 2 mm Width ±10 ppm Frequency XRCGB26M000F1S2ER0

Murata XRCGB26M000F1S2ER0 is a high-precision 26 MHz crystal unit designed for surface mount applications, featuring a 4-pin package and compact dimensions of 1.6 mm length, 2 mm width, and 0.65 mm height. This crystal unit delivers ±10 ppm frequency tolerance, making it suitable for devices requiring accurate frequency control.

The unit supports a load capacitance of 7 pF and has a series resistance of 50 ohms, providing stable oscillation characteristics. Its operating temperature range from -30°C to 85°C ensures reliable performance under various environmental conditions.

Manufactured in Japan, this crystal unit employs advanced package technology and premium quartz crystal elements, contributing to its small size and high frequency accuracy. Typical applications include communication clocks for Wi-Fi and Bluetooth devices, PCs, visual equipment, and portable electronics where minimizing PCB footprint is essential.

The component complies with environmental standards, being lead-free and RoHS compliant. It is supplied in tape packaging, facilitating automated placement in mass production. The crystal unit operates at a standard frequency of 26 MHz.

Designed for surface mount with 4-pin configuration. Load capacitance rated at 7 pF. Compact dimensions of 1.6 mm by 2 mm by 0.65 mm. Operating temperature range from -30°C to 85°C ensures durability. Series resistance of 50 ohms supports optimal signal quality.

Manufactured in Japan with high-grade quartz crystal elements. Complies with RoHS directive being lead-free and environmentally safe.

This Murata Crystal Unit is ideal for industrial electronics, telecommunications, computing equipment, and portable devices requiring precise and stable frequency references. Explore more premium electronic components for your design and manufacturing needs at EnvMart.
